Car Range

Alto
  • Exterior
  • Interiors
  • Comfort
  • Utility
  • Safety
Exterior
  STD (O) LXI(O) LXI(O)(CNG) VXI VXI+
Body Coloured Bumpers
Body Coloured Outside Door Handles
Wheel Covers Center Cap Full Full Full Full
Body Side Molding
Interiors
  STD (O) LXI(O) LXI(O)(CNG) VXI VXI+
Dual Tone Interiors
B & C Pillar Upper Trims
C Pillar Lower Trim (Molded)
Seat Upholestry Vinyl Fabric + Vinyl Fabric + Vinyl Fabric + Vinyl Fabric + Vinyl
Silver Accent Inside Door Handles
Silver Accent on Steering Wheels
Silver Accent on Louvers
Silver Accent on Center Garnish
Comfort
  STD (O) LXI(O) LXI(O)(CNG) VXI VXI+
Air Conditioner with Heater
Power Steering
Front Power Windows
Center Door Locking
Remote Keyless Entry
Audio (With USB, Aux-In & Radio)
Smartplay Dock
Smartplay Studio - 17.78 cm Touch Screen Infotainment System
Bluetooth Connectivity
Front Speaker (2) with Speaker Grille
Accessory Socket
Rear Parcel Tray
Assist Grips(Co - Dr. +Rear)
Digital Clock (In Speedometer Display)
Sun visor Dr. +Co Dr. Dr. +Co Dr. Dr. +Co Dr. Dr. +Co Dr. Dr. +Co Dr.
RR Seat Head Rest - Integrated Type
Remote Back Door Opener
Internally Adjustable ORVM
Remote Fuel Lid Opener
Utility
  STD (O) LXI(O) LXI(O)(CNG) VXI VXI+
Front Console Bottle Holder
Rear Console Bottle Holder
Front Door Trim Map Pocket (Dr.)
Front Door Trim Map Pocket (Passenger)
Safety
  STD (O) LXI(O) LXI(O)(CNG) VXI VXI+
Headlight Levelling
RR Seat Belt ELR Type
High-Mounted Stop Lamp
Immobiliser
Front Wiper & Washer 2 Speed 2 Speed+Intermittent 2 Speed+Intermittent 2 Speed+Intermittent 2 Speed+Intermittent
Collapsible Steering Column
Tubeless Tyres
Rear Door Child Lock
Driver Side Airbag
Passenger Airbag
Reverse Parking Sensor
ABS with EBD
Seat Belt Reminder - Dr.+ Co - Dr.
Speed Alert System
  • Dimensions
  • Weight
  • Engine
  • Suspension System
  • Capacity
  • Tyres
  • Brakes
Dimensions
  STD (O) LXI(O) LXI(O)(CNG) VXI VXI+
Overall Length 3445 mm 3445 mm 3445 mm 3445 mm 3445 mm
Overall Width (Without Side Molding) 1490 mm 1490 mm 1490 mm 1490 mm 1490 mm
Overall Width (With side moulding) 1515 mm 1515 mm 1515 mm 1515 mm 1515 mm
Overall Height (Unladen) 1475 mm 1475 mm 1475 mm 1475 mm 1475 mm
Wheelbase 2360 mm 2360 mm 2360 mm 2360 mm 2360 mm
Tread (Front) 1295 mm 1295 mm 1295 mm 1295 mm 1295 mm
Tread (Rear) 1290 mm 1290 mm 1290 mm 1290 mm 1290 mm
Turning Radius 4.6 m 4.6 m 4.6 m 4.6 m 4.6 m
Weight
  STD (O) LXI(O) LXI(O)(CNG) VXI VXI+
Gross Weight 1185 1185 1185 1185 1185
Kerb Weight 732 757 850 762 762
Engine
  STD (O) LXI(O) LXI(O)(CNG) VXI VXI+
Swept Volume 796 cc 796 cc 796 cc 796 cc 796 cc
Engine Type F8D F8D F8D F8D F8D
Number of Cylinders 3 3 3 3 3
Number of Valves 12 12 12 12 12
Maximum Power(petrol) 35.3 Kw @ 6000 rpm 35.3 Kw @ 6000 rpm 35.3 Kw @ 6000 rpm 35.3 Kw @ 6000 rpm 35.3 Kw @ 6000 rpm
Maximum Power(CNG) 30.1 kW @ 6000 rpm 30.1 kW @ 6000 rpm 30.1 kW @ 6000 rpm 30.1 kW @ 6000 rpm 30.1 kW @ 6000 rpm
Maximum Torque(Petrol) 69 Nm @ 3500 rpm 69 Nm @ 3500 rpm 69 Nm @ 3500 rpm 69 Nm @ 3500 rpm 69 Nm @ 3500 rpm
Maximum Torque(CNG) 60 Nm @ 3500 rpm 60 Nm @ 3500 rpm 60 Nm @ 3500 rpm 60 Nm @ 3500 rpm 60 Nm @ 3500 rpm
Transmission 5 Speed MT 5 Speed MT 5 Speed MT 5 Speed MT 5 Speed MT
Suspension System
  STD (O) LXI(O) LXI(O)(CNG) VXI VXI+
Front Mac Pherson Strut Mac Pherson Strut Mac Pherson Strut Mac Pherson Strut Mac Pherson Strut
Rear 3-Link Rigid Axle Suspension 3-Link Rigid Axle Suspension 3-Link Rigid Axle Suspension 3-Link Rigid Axle Suspension 3-Link Rigid Axle Suspension
Capacity
  STD (O) LXI(O) LXI(O)(CNG) VXI VXI+
Seating 5 Persons 5 Persons 4 Persons 5 Persons 5 Persons
Fuel Tank 35 L 35 L 35 L(Petrol)/
60 L (CNG)(Water Equivalent Filling Capacity) 		35 L 35 L
Tyres
  STD (O) LXI(O) LXI(O)(CNG) VXI VXI+
Tyre Size 145/80 R12 (Tubeless) 145/80 R12 (Tubeless) 145/80 R12 (Tubeless) 145/80 R12 (Tubeless) 145/80 R12 (Tubeless)
Brakes
  STD (O) LXI(O) LXI(O)(CNG) VXI VXI+
Front Disc Disc Disc Disc Disc
Rear Drum Drum Drum Drum Drum
Alto K10
  • Interiors
  • Comfort & Convenience
  • Infotainment
  • Safety
  • Exteriors
Interiors
  STD MT LXi MT VXi MT VXi AGS VXi CNG VXi+ MT VXi+ AGS
Sun Visor Dr.+Co Dr Dr.+Co Dr Dr.+Co Dr Dr.+Co Dr Dr.+Co Dr Dr.+Co Dr Dr.+Co Dr
Rear Parcel Tray
Assist Grips Co- Dr. Co- Dr. Co- Dr. + Rear Co- Dr. + Rear Co- Dr. + Rear Co- Dr. + Rear Co- Dr. + Rear
Front console utility space
1L Bottle Holder in Front doors with Map Pockets
Silver Accent Inside Door Handles
Silver Accent on Steering Wheel
Silver Accent on Side Louvers
Silver Accent on Center Garnish
Comfort & Convenience
  STD MT LXi MT VXi MT VXi AGS VXi CNG VXi+ MT VXi+ AGS
Cabin Air Filter
Front Power Windows
Internally Adjustable ORVMs
Remote Keyless Entry
Remote Back Door Opener
Remote Fuel Lid Opener
Accessory Socket
Air Conditioner with Heater
Power Steering
Infotainment
  STD MT LXi MT VXi MT VXi AGS VXi CNG VXi+ MT VXi+ AGS
Touch Screen Audio 17.78 cm
(SmartPlay Studio)		 17.78 cm
(SmartPlay Studio)
Media Receiver (AM/FM/Bluetooth) SmartPlay
Dock		 SmartPlay
Dock		 SmartPlay
Dock		 SmartPlay
Studio		 SmartPlay
Studio
AUX Port
USB Port
Remote Application
Bluetooth
Android Auto
Apple Carplay
Speakers 2 2 2 4 4
Steering Mounted Audio & Voice Control
Digital Speedometer
Distance to Empty    *^    *^    *^
Fuel Consumption - Average    *^    *^    *^
Fuel Consumption - Instantaneous    *^    *^    *^
Gear Shift Indicator (MT only)
(Petrol
Variant Only)
(Petrol
Variant Only)
(Petrol
Variant Only)
Gear Position Indicator (AGS only)
Low Fuel Warning SmartPlay
Dock		 SmartPlay
Dock		 SmartPlay
Dock		 SmartPlay
Studio		 SmartPlay
Studio
Door Ajar Warning SmartPlay
Dock		 SmartPlay
Dock		 SmartPlay
Dock		 SmartPlay
Studio		 SmartPlay
Studio
Key off/Head lamp on Reminder
*^For VXI CNG variant, fuel consumption related data available only in Petrol Mode.
Safety
  STD MT LXi MT VXi MT VXi AGS VXi CNG VXi+ MT VXi+ AGS
Rear Door Child lock
Engine Immobiliser
Speed Sensing Auto Door Lock
Central Door Locking
Impact Sensing Door Unlock
High Speed Alert^
Front Seat Belts Pre-Tensioner & Force Limiter
Rear Seat Belt Center(2-Point Static)
(Petrol
Variant Only)
(Petrol
Variant Only)
(Petrol
Variant Only)
Rear Seat Belt Outboard(3-Point)
(Static)
(Static)
(ELR)
(ELR)
(ELR)
(ELR)
(ELR)
Dual Front Airbags##
ABS with EBD
Reverse Parking Sensor
Seat Belt Reminder - Dr.+ Co - Dr.
HEARTECT Platform
Headlamp Levelling
High-Mounted Stop Lamp
Collapsible Steering Column
^The Speed Alert System gives audible warning for alert of over-speed to driver.
##For details on functioning of safety features,including air bag, kindly refer to the Owner's Manual.
Exteriors
  STD MT LXi MT VXi MT VXi AGS VXi CNG VXi+ MT VXi+ AGS
Roof Antenna
Body Coloured Bumpers
Body Coloured Outside Door Handles
Wheel Covers Center Cap Center Cap Full Full Full Full Full
  • Dimensions
  • Engine
  • Transmission
  • Suspension
  • Brakes & Tyre
Dimensions
  STD MT LXi MT VXi MT VXi AGS VXi CNG VXi+ MT VXi+ AGS
Overall Length (mm) 3530 3530 3530 3530 3530 3530 3530
Overall Width (mm) 1490 1490 1490 1490 1490 1490 1490
Overall Height (Unladen) (mm) 1520 1520 1520 1520 1520 1520 1520
Wheelbase(mm) 2380 2380 2380 2380 2380 2380 2380
Turning Radius(m) 4.5 4.5 4.5 4.5 4.5 4.5 4.5
Seating Capacity 5 Persons 5 Persons 5 Persons 5 Persons 4 Persons 5 Persons 5 Persons
Boot Space(L)# 214 214 214 214 214 214
#VDA method.
Engine
  STD MT LXi MT VXi MT VXi AGS VXi CNG VXi+ MT VXi+ AGS
Engine Type K10C K10C K10C K10C K10C CNG K10C K10C
Fuel type Petrol Petrol Petrol Petrol Petrol + CNG Petrol Petrol
Piston Displacement (cc) 998 998 998 998 998 998 998
Maximum Power (kW@rpm) (1 kW = 1.35962 PS) 49 kW @
5500 rpm		 49 kW @
5500 rpm		 49 kW @
5500 rpm		 49 kW @
5500 rpm		 41.7 kW @
5300 rpm (CNG Mode)
48 kW @
5500 rpm (Petrol Mode) 		49 kW @
5500 rpm		 49 kW @
5500 rpm
Maximum Torque (Nm@rpm) 89 Nm @
3500 rpm 		89 Nm @
3500 rpm 		89 Nm @
3500 rpm 		89 Nm @
3500 rpm 		82.1 Nm @
3400 rpm (CNG Mode)
89 Nm @
3500 rpm (Petrol Mode) 		89 Nm @
3500 rpm 		89 Nm @
3500 rpm
Emission Standard BS VI BS VI BS VI BS VI BS VI BS VI BS VI
Fuel Tank Capacity(L) 27 27 27 27 27 (Petrol Mode)
55 (CNG Mode)
(Water Equivalent) 		27 27
Transmission
  STD MT LXi MT VXi MT VXi AGS VXi CNG VXi+ MT VXi+ AGS
Transmission Type 5MT/AGS 5MT/AGS 5MT/AGS 5MT/AGS 5MT 5MT/AGS 5MT/AGS
Suspension
  STD MT LXi MT VXi MT VXi AGS VXi CNG VXi+ MT VXi+ AGS
Front Mac Pherson
Strut with Coil Spring 		Mac Pherson
Strut with Coil Spring 		Mac Pherson
Strut with Coil Spring 		Mac Pherson
Strut with Coil Spring 		Mac Pherson
Strut with Coil Spring 		Mac Pherson
Strut with Coil Spring 		Mac Pherson
Strut with Coil Spring
Rear Torsion Beam
with Coil Spring		 Torsion Beam
with Coil Spring		 Torsion Beam
with Coil Spring		 Torsion Beam
with Coil Spring		 Torsion Beam
with Coil Spring		 Torsion Beam
with Coil Spring		 Torsion Beam
with Coil Spring
Brakes & Tyre
  STD MT LXi MT VXi MT VXi AGS VXi CNG VXi+ MT VXi+ AGS
Front Disc Disc Disc Disc Disc Disc Disc
Rear Drum Drum Drum Drum Drum Drum Drum
Tyre Size 145/80 R13 145/80 R13 145/80 R13 145/80 R13 145/80 R13 145/80 R13 145/80 R13
Celerio
  • Exteriors
  • Interiors
  • Comfort and Convenience
  • Central Console & Instrument Panel
  • Safety & Security
  • New Technology
Exteriors
LXi MT VXi MT VXi CNG ZXi MT ZXi+ MT VXi AGS ZXi AGS ZXi+ AGS
ORVM with Turn Indicators
Front Fog Lamps
Body Coloured Bumper
Body Coloured ORVMs
Body Coloured Outside Door Handles
Chrome accent on front grille
B Pillar Black Out Tape
Full Wheel Covers

(Center cap)
15" (38.02cm) Alloy Wheels
Interiors
LXi MT VXi MT VXi CNG ZXi MT ZXi+ MT VXi AGS ZXi AGS ZXi+ AGS
Co-Dr Vanity Mirror in Sun Visor
Dr. Side Sunvisor with ticket holder
Day Night IRVM
Front Cabin Lamp (3 Positions)
Bottle Holder 6 6 6 6 6 6 6 6
Driver Seat Height Adjuster
Front Seat Back Pockets (Passenger Side)
Rear Seat (60:40 split)
Front and Rear Headrest Integrated Integrated Integrated Integrated Integrated Integrated Integrated Integrated
Rear Parcel Shelf
Comfort &Convenience
LXi MT VXi MT VXi CNG ZXi MT ZXi+ MT VXi AGS ZXi AGS ZXi+ AGS
Air Conditioner(Manual)
Pollen Filter
Engine Push Start/Stop with Smart Key
Smartplay Studio System with Smartphone Navigation and Voice Command (Android Auto and Apple CarPlay enabled)
Smart Play Dock - USB, FM, AUX, BT
No. of Speakers 4 4 4 4
Remote keyless Entry
Security System
Central Door Lock (5 Doors)
Power Windows Fr/Rr Fr/Rr Fr/Rr Fr/Rr Fr/Rr Fr/Rr Fr/Rr
Power Windows - Auto Down (Driver Side)
Outside Mirror Types Flap Type Electrically Adjustable Electrically Adjustable Electrically Adjustable Electrically Adjustable Electrically Adjustable Electrically Adjustable Electrically Adjustable
Electrically-Foldable ORVM
Steering- Mounted Audio Controls
Steering-Mounted Voice Control
Power Steering
Central Consol & Instrument Panel
LXi MT VXi MT VXi CNG ZXi MT ZXi+ MT VXi AGS ZXi AGS ZXi+ AGS
Illumination Colour Amber Amber Amber Amber Amber Amber Amber Amber
Tachometer
Urethane Steering Wheel
Tilt Steering
Accessory Socket
Dial-Type Climate Control Black Silver Painted Silver Painted Silver Painted Silver Painted Silver Painted Silver Painted Silver Painted
Fuel Consumption (Instantaneous and avg.)
Distance to Empty
Gear Position Indicator
Gear Shift Indicator
Door Ajar Warning Lamp
Headlamp Warning
Low Fuel Warning
Key Off/Headlamp on Reminder
Safety & Security
LXi MT VXi MT VXi CNG ZXi MT ZXi+ MT VXi AGS ZXi AGS ZXi+ AGS
Driver Airbag##
Passenger Airbags##
Seat Belt Reminder with Buzzer (Front + Rear Seat)**#
Seat Belt Pre-Tensioner & Force Limiters (Dr. + Co-Dr.)
Seat Belt for all Seats
Hill Hold Assist
Impact-Sensing Auto Door Unlock
Pedestrian Protection
ABS with EBD
ESC
Speed-Sensitive Auto Door Lock
Headlight Leveling
Rear Window Wiper & Washer
Front Ventilated Disc
Immobilizer
Child-Proof Rear Door Locks
Rear Defogger
Speed Alert System^
Reverse Parking Assist Sensors
##For details on functioning of safety features, including air bag, kindly refer to the Owner's Manual.
**#Seat belt reminder comes on unless all rear passenger's seat belts are fastened irrespective of the presence or absence of passenger.
^The speed alert system gives audible warning for alert of over-speed to driver. When Vehicle speed exceeds 80km/h, primary level warning with two beeps will sound every minute. When the vehicle speed exceeds about 120 km/h, secondary level warning with continuous beeps will sound. If the vehicle speed is slowed down to about 118 km/h, primary warning will resume. If the vehicle is slowed down to about 78 km/h speed alert warning will stop. This buzzer does not indicate any malfunction in vehicle.
New Technology
LXi MT VXi MT VXi CNG ZXi MT ZXi+ MT VXi AGS ZXi AGS ZXi+ AGS
Engine Idle Start Stop (Petrol) (Petrol)
Hill Hold Assist
  • Dimensions (in mm)
  • Engine
  • Transmission
  • Suspension System
  • Weight(kg)
  • Capacity
  • Power Steering
  • Tyres
  • Brakes
Dimensions
LXi MT VXi MT ZXi MT ZXi+ MT VXi AGS ZXi AGS ZXi+ AGS VXi CNG
Overall Length 3695 3695 3695 3695 3695 3695 3695 3695
Overall Width 1655 1655 1655 1655 1655 1655 1655 1655
Overall Height 1555 1555 1555 1555 1555 1555 1555 1555
Wheelbase 2435 2435 2435 2435 2435 2435 2435 2435
Tread Front 1430(R14),
1440(R15) 		1430(R14),
1440(R15)		 1430(R14),
1440(R15)		 1430(R14),
1440(R15)		 1430(R14),
1440(R15)		 1430(R14),
1440(R15)		 1430(R14),
1440(R15)		 1430(R14),
1440(R15)
Tread Rear 1440(R14),
1450(R15)		 1440(R14),
1450(R15)		 1440(R14),
1450(R15)		 1440(R14),
1450(R15)		 1440(R14),
1450(R15)		 1440(R14),
1450(R15)		 1440(R14),
1450(R15)		 1440(R14),
1450(R15)
Engine
LXi MT VXi MT ZXi MT ZXi+ MT VXi AGS ZXi AGS ZXi+ AGS VXi CNG
Type K10C K10C K10C K10C K10C K10C K10C K10C CNG
Capacity 998cc 998cc 998cc 998cc 998cc 998cc 998cc 998cc
Engine Type Aluminium Aluminium Aluminium Aluminium Aluminium Aluminium Aluminium Aluminium
Number of Cylinders 3 3 3 3 3 3 3 3
Number of Valves in Each Cylinder 4 4 4 4 4 4 4 4
Maximum Output 49kW (66.62Ps) @ 5500rpm 49kW (66.62Ps) @ 5500rpm 49kW (66.62Ps) @ 5500rpm 49kW (66.62Ps) @ 5500rpm 49kW (66.62Ps) @ 5500rpm 49kW (66.62Ps) @ 5500rpm 49kW (66.62Ps) @ 5500rpm CNG Mode: 41.7kW (56.70Ps) @ 5300rpm
Gasoline Mode: 48kW (65.26Ps) @ 5500rpm
Maximum Torque 89Nm @ 3500rpm 89Nm @ 3500rpm 89Nm @ 3500rpm 89Nm @ 3500rpm 89Nm @ 3500rpm 89Nm @ 3500rpm 89Nm @ 3500rpm CNG Mode: 82.1Nm @ 3400rpm
Gasoline Mode: 89Nm @ 3500rpm
Emmision Standard Type BS VI + OBD II BS VI + OBD II BS VI + OBD II BS VI + OBD II BS VI + OBD II BS VI + OBD II BS VI + OBD II BS VI + OBD II
Accelerator Pedal Type Electric Type Electric Type Electric Type Electric Type Electric Type Electric Type Electric Type Electric Type
Transmission
LXi MT VXi MT ZXi MT ZXi+ MT VXi AGS ZXi AGS ZXi+ AGS VXi CNG
Type 5MT/Auto Gear Shift 5MT/Auto Gear Shift 5MT/Auto Gear Shift 5MT/Auto Gear Shift 5MT/Auto Gear Shift 5MT/Auto Gear Shift 5MT/Auto Gear Shift 5MT
Suspension System
LXi MT VXi MT ZXi MT ZXi+ MT VXi AGS ZXi AGS ZXi+ AGS VXi CNG
Front Mac Pherson Strut with Coil Spring Mac Pherson Strut with Coil Spring Mac Pherson Strut with Coil Spring Mac Pherson Strut with Coil Spring Mac Pherson Strut with Coil Spring Mac Pherson Strut with Coil Spring Mac Pherson Strut with Coil Spring Mac Pherson Strut with Coil Spring
Rear Torsion Beam with Coil Spring Torsion Beam with Coil Spring Torsion Beam with Coil Spring Torsion Beam with Coil Spring Torsion Beam with Coil Spring Torsion Beam with Coil Spring Torsion Beam with Coil Spring Torsion Beam with Coil Spring
Weight(kg)
LXi MT VXi MT ZXi MT ZXi+ MT VXi AGS ZXi AGS ZXi+ AGS VXi CNG
Kerb Weight 800kg 810kg 810kg 820kg 815kg 820kg 825kg 905kg
Gross Vehicle Weight 1260 1260 1260 1260 1260 1260 1260 1320
Capacity
LXi MT VXi MT ZXi MT ZXi+ MT VXi AGS ZXi AGS ZXi+ AGS VXi CNG
Seating Capacity | Persons 5 5 5 5 5 5 5 5
Luggage Capacity (L) 313*** 313*** 313*** 313*** 313*** 313*** 313***
Fuel Tank Capacity (L) 32 32 32 32 32 32 32 Petrol:32
CNG:60(Water Equivalent)
***VDA Method
Power Steering
LXi MT VXi MT ZXi MT ZXi+ MT VXi AGS ZXi AGS ZXi+ AGS VXi CNG
Type Electric Power Steering Electric Power Steering Electric Power Steering Electric Power Steering Electric Power Steering Electric Power Steering Electric Power Steering Electric Power Steering
Tyres
LXi MT VXi MT ZXi MT ZXi+ MT VXi AGS ZXi AGS ZXi+ AGS VXi CNG
Tyre Size** 165/70R14 165/70R14 165/70R14 175/60R15 165/70R14 165/70R14 175/60R15 165/70R14
**Spare wheel material is steel (for all variants) and tyre size is 165/70 R14.
Brakes
LXi MT VXi MT ZXi MT ZXi+ MT VXi AGS ZXi AGS ZXi+ AGS VXi CNG
Front Disc Disc Disc Disc Disc Disc Disc Disc
Rear Drum Drum Drum Drum Drum Drum Drum Drum
Dzire
  • EXTERIOR
  • INTERIOR
  • SAFETY AND SECURITY
  • AUDIO AND ENTERTAINMENT
  • COMFORT & CONVENIENCE
  • TRANSMISSION
EXTERIOR
LXi MT VXi MT VXi AMT VXi CNG MT ZXi MT ZXi AMT ZXi CNG MT ZXi+ MT ZXi+ AMT
LED Projector Headlamps
Daylight Running Lamps
Rear Combination LED Lamp
High Mounted LED Stop Lamp
Body Coloured Door Handles
Body Coloured ORVMs
Side Turn Indicators on ORVMs
Wheels (Steel/Alloy/Precision-cut Alloy) Steel Steel Steel Steel Alloy Alloy Alloy Precision Cut Alloy Precision Cut Alloy
Wheel Cover
Door Outer-Weather Strip Black Black Black Black Chrome Chrome Chrome Chrome Chrome
INTERIORS
LXi MT VXi MT VXi AMT VXi CNG MT ZXi MT ZXi AMT ZXi CNG MT ZXi+ MT ZXi+ AMT
Leather Wrapped Steering Wheel
Modern Wood Accent With Natural Gloss Finish
Dual-Tone Interiors
Multi-Information Display (Coloured) (Coloured)
Outside Temperature Display AMT Only AMT Only
Low-Fuel Warning Lamp
Urbane Satin Chrome Accents on Console, Gear Lever and Steering Wheel
Front Dome Lamp
Tachometer
Front Door Armrest with Fabric
Co. Driver Side Sunvisor with Vanity Mirror
Driver Side Sunvisor with Ticket Holder
SAFETY AND SECURITY
LXi MT VXi MT VXi AMT VXi CNG MT ZXi MT ZXi AMT ZXi CNG MT ZXi+ MT ZXi+ AMT
Suzuki HEARTECT body
ABS With EBD and Brake Assist
ESP with Hill Hold Assist (AMT Only)
Dual Airbags##
Reverse Parking Sensors
Reverse Parking Camera
Anti-theft Security System
Front Fog Lamps
Rear Defogger
ISOFix Child Seat Anchorages
Front Seat Belt with Pre-Tensioner
Pinch Guard Power Window (Driver)
Engine Immobilizer
Speed-Sensitive Door Locking
Night and Day Adjustable IRVM
^Speed Alert
Driver & Co-Driver Seat Belt Reminder
Key-Left Warning Lamp & Buzzer
Front Fog Lamp Garnish Silver Chrome Chrome Chrome Chrome Chrome Chrome Chrome Chrome
Door Ajar Warning Lamp
^The speed alert system gives audible warning for alert of over-speed to driver. When vehicle speed exceeds about 80 Km/h, primary level warning with two beeps will sound every minute. When the vehicle speed about 120 Km/h, secondary level warning with continuous beeps will sound.If the Vehicle Speed is slowed down to about 118 km/h, primary warning will resume. If the vehicle is slowed down to about 78 km/h, speed alert warning will stop. This buzzer does not indicate any malfunction in vehicle.
##For details on functioning of safety features, including air bag, kindly refer to the Owner's Manual.
AUDIO AND ENTERTAINMENT
LXi MT VXi MT VXi AMT VXi CNG MT ZXi MT ZXi AMT ZXi CNG MT ZXi+ MT ZXi+ AMT
All New Feather Touch Audio System
Smartplay Studio System with Navigation and Voice Command (Android Auto and Apple CarPlay enabled)
AHA Platform (Through Smartplay Studio App)
Audio Player with USB, CD, AUX and FM/AM with Bluetooth Connectivity
Steering Mounted Audio & Calling Controls
Audio Remote Control (Through Smartplay Studio app) (Through Smartplay Studio app) (Through Smartplay Studio app) (Through Smartplay Studio app) (Through Smartplay Studio app)
COMFORT AND CONVENIENCE
LXi MT VXi MT VXi AMT VXi CNG MT ZXi MT ZXi AMT ZXi CNG MT ZXi+ MT ZXi+ AMT
Engine Push Start-Stop Button with Smart Key
Auto Headlamp (Lead me to vehicle/follow me home)
Rear AC Vent
Rear Seat Center Armrest with Cup Holder
Remote Keyless Entry System
Manual Air Conditioner with Heater
Automatic Climate Control
Pollen Filter
Front Accessory Socket
Rear Accessory Socket with Mobile Pocket
Central Locking
Electromagnetic Trunk Opening
Gear Shift Indicator (MT Only)
Power Windows (Front + Rear)
Electrically Adjustable ORVMs
Electrically Foldable ORVMs (Key Sync) (Key Sync)
Cruise Control
Driver Side Auto Down Power Window
Driver Side Auto Up Power Window
Tilt Steering
Height Adjustable Driver Seat
Adjustable Front Seat Headrests
Luggage Room Lamp
Bottle Holder on All Doors
TRANSMISSION
LXi MT VXi MT VXi AMT VXi CNG MT ZXi MT ZXi AMT ZXi CNG MT ZXi+ MT ZXi+ AMT
Door Speakers (4 Speakers)
Tweeters
Antenna
  • DIMENSION
  • ENGINE
  • TRANSMISSION
  • BRAKES
  • STEERING
  • SUSPENSION
  • OTHERS
DIMENSIONS
LXi MT VXi MT VXI AMT VXI CNG MT ZXI MT ZXI AMT ZXI CNG MT ZXI+ MT ZXI+ AMT
Length (mm) 3995 3995 3995 3995 3995 3995 3995 3995 3995
Width (mm) 1735 1735 1735 1735 1735 1735 1735 1735 1735
Height (mm) 1515(Unladen) 1515(Unladen) 1515(Unladen) 1515(Unladen) 1515(Unladen) 1515(Unladen) 1515(Unladen) 1515(Unladen) 1515(Unladen)
Wheelbase(mm) 2450 2450 2450 2450 2450 2450 2450 2450 2450
Boot Space (L) 378 378 378 378 378 378 378
ENGINE
LXi MT VXi MT VXI AMT VXI CNG MT ZXI MT ZXI AMT ZXI CNG MT ZXI+ MT ZXI+ AMT
Engine Capacity 1197 1197 1197 1197 1197 1197 1197 1197 1197
Max Power (kW@rpm) 66 kW @ 6000rpm 66 kW @ 6000rpm 66 kW @ 6000rpm 57kW @ 6000 rpm 66 kW @ 6000rpm 66 kW @ 6000rpm 57kW @ 6000 rpm 66 kW @ 6000rpm 66 kW @ 6000rpm
Max Torque (Nm@rpm) 113 Nm @ 4400 rpm 113 Nm @ 4400 rpm 113 Nm @ 4400 rpm 98.5 Nm @ 4300 rpm 113 Nm @ 4400 rpm 113 Nm @ 4400 rpm 98.5 Nm @ 4300 rpm 113 Nm @ 4400 rpm 113 Nm @ 4400 rpm
Number of cylinders 4 4 4 4 4 4 4 4 4
TRANSMISSION
LXi MT VXi MT VXI AMT VXI CNG MT ZXI MT ZXI AMT ZXI CNG MT ZXI+ MT ZXI+ AMT
Types 5MT/5AMT 5MT/5AMT 5MT/5AMT 5MT 5MT/5AMT 5MT/5AMT 5MT 5MT/5AMT 5MT/5AMT
Brakes
LXi MT VXi MT VXI AMT VXI CNG MT ZXI MT ZXI AMT ZXI CNG MT ZXI+ MT ZXI+ AMT
Front Disc Disc Disc Disc Disc Disc Disc Disc Disc
Rear Drum Drum Drum Drum Drum Drum Drum Drum Drum
STEERING
LXi MT VXi MT VXI AMT VXI CNG MT ZXI MT ZXI AMT ZXI CNG MT ZXI+ MT ZXI+ AMT
Turning Radius (m) 4.8 4.8 4.8 4.8 4.8 4.8 4.8 4.8 4.8
Power Steering Type Electric Electric Electric Electric Electric Electric Electric Electric Electric
SUSPENSION
LXi MT VXi MT VXI AMT VXI CNG MT ZXI MT ZXI AMT ZXI CNG MT ZXI+ MT ZXI+ AMT
Front Mac Pherson Strut Mac Pherson Strut Mac Pherson Strut Mac Pherson Strut Mac Pherson Strut Mac Pherson Strut Mac Pherson Strut Mac Pherson Strut Mac Pherson Strut
Rear Torsion Beam Torsion Beam Torsion Beam Torsion Beam Torsion Beam Torsion Beam Torsion Beam Torsion Beam Torsion Beam
Others
LXi MT VXi MT VXI AMT VXI CNG MT ZXI MT ZXI AMT ZXI CNG MT ZXI+ MT ZXI+ AMT
Fuel Tank Capacity (L) 37L 37L 37L

Petrol: 37L

CNG: 55L (water equivalent)

 37L 37L

Petrol: 37L

CNG: 55L (water equivalent)

 37L 37L
Kerb Weight (kg) 880-915 kg 880-915 kg 880-915 kg 990-995 kg 880-915 kg 880-915 kg 990-995 kg 880-915 kg 880-915 kg
Gross Vehicle Weight (kg) 1335 kg 1335 kg 1335 kg 1405 kg 1335 kg 1335 kg 1405 kg 1335 kg 1335 kg
Seating Capacity 5 5 5 5 5 5 5 5 5
Tyre Size (Steel) 165/80 R14 165/80 R14 165/80 R14 165/80 R14 165/80 R14 165/80 R14 165/80 R14 165/80 R14 165/80 R14
Tyre Size (Alloy) 185/65 R15 185/65 R15 185/65 R15 185/65 R15 185/65 R15 185/65 R15 185/65 R15 185/65 R15 185/65 R15
Eeco
  • Comfort
  • Instrument Panel & Console
  • Interior
  • Exterior
  • Safety & Security
  • Facilities On Board
Comfort
  5 Seater Standard 5 Seater AC 5 Seater AC CNG 7 Seater Standard Ambulance Ambulance Shell*
Air Conditioner
Heater
Reclining Front Seats
Sliding Driver Seat
Head Rest-Front Row Integrated Integrated Integrated Integrated Integrated Integrated
Head Rest-Second Row Fixed, Pillow Fixed, Pillow Fixed, Pillow Fixed, Pillow
Head Rest-Third Row Fixed, Pillow
Seat Back Pocket (Co-Driver Seat)
*Ambulance shell is incompletely built vehicle, for fabrication of Type B Road Ambulance, with recommended seating capacity of 3 Persons + 1 Patient.
Instrument Panel & Console
  5 Seater Standard 5 Seater AC 5 Seater AC CNG 7 Seater Standard Ambulance Ambulance Shell*
Illuminated Hazard Switch
Digital Display in Instrument Cluster
12 Volt Accessory Socket
Multi Tripmeter
Digital Speedometer
Dome Lamp Battery Saver Function
*Ambulance shell is incompletely built vehicle, for fabrication of Type B Road Ambulance, with recommended seating capacity of 3 Persons + 1 Patient.
Interior
  5 Seater Standard 5 Seater AC 5 Seater AC CNG 7 Seater Standard Ambulance Ambulance Shell*
Cabin Air Filter
Both Side Sunvisor
Assist Grip (Co-Driver + Rear)
Molded Roof Lining
Molded Floor Carpet
Dual Interior Color
Seat Matching Interior Color
Front Cabin Lamp
Rear Cabin Lamp
Steering Lock
*Ambulance shell is incompletely built vehicle, for fabrication of Type B Road Ambulance, with recommended seating capacity of 3 Persons + 1 Patient.
Exterior
  5 Seater Standard 5 Seater AC 5 Seater AC CNG 7 Seater Standard Ambulance Ambulance Shell*
Wheel Cover Center Cap Center Cap Center Cap Center Cap Center Cap Center Cap
Front Mud Flaps
Outside Rear View Mirror (Left & Right)
Ambulance Decal - Front & Rear
Partly Frosted Rear side windows
Partly Frosted Back Door windows
*Ambulance shell is incompletely built vehicle, for fabrication of Type B Road Ambulance, with recommended seating capacity of 3 Persons + 1 Patient.
Safety & Security
  5 Seater Standard 5 Seater AC 5 Seater AC CNG 7 Seater Standard Ambulance Ambulance Shell*
Immobilizer
Headlamp Leveling
Side Impact Beams
Child Lock for Sliding Doors & Windows
Offset Crash (as per AIS 098)**
Seat Belts for all Seats
High Mount Stop Lamp
Reverse Parking Sensor System
Seat Belt Reminder (Dr + Co-Dr)
Speed Alert System
ABS with EBD
Dual Airbag
*Ambulance shell is incompletely built vehicle, for fabrication of Type B Road Ambulance, with recommended seating capacity of 3 Persons + 1 Patient.
**Crash Compliance is with Offset Crash (as per AIS 098).
Facilities On Board
  5 Seater Standard 5 Seater AC 5 Seater AC CNG 7 Seater Standard Ambulance Ambulance Shell*
Revolving Roof Lamp
Molded Rubber Matting in Rear Cabin
Siren
Public Address System (Amplifier, Mike and Speaker)
Two LED lights inside Rear Cabin for Illuminated
Stretcher Assembly (Monoblock Stretcher)
Attendant's Seat
Space for First Aid and Nursing Kit
Oxygen Cylinder Clamp
Hook for Infusion Mounting
*Ambulance shell is incompletely built vehicle, for fabrication of Type B Road Ambulance, with recommended seating capacity of 3 Persons + 1 Patient.
  • Dimension & Weight
  • Engine (Petrol and CNG)
  • Transmission
  • Brake/Chassis
Dimension & Weight
  5 Seater Standard 5 Seater AC 5 Seater AC CNG 7 Seater Standard Ambulance Ambulance Shell*
Fuel Efficiency 19.71 km/l 19.71 km/l 26.78 km/kg 19.71 km/l
Kerb Weight (kg) 935 935 1050 935 1030 940
Full Length (mm) 3675 3675 3675 3675 3675 3675
Full Width (mm) 1475 1475 1475 1475 1475 1475
Full Height (mm) Unladen 1825 1825 1825 1825 1930
(excluding
top light)		 1930
(excluding
top light)
Seating Capacity 5 5 5 7 3+1
(Patient)		 3
(with recommended
seating capacity
of 3 person + 1 patient
after fabrication)
Tread Front (mm) 1280 1280 1280 1280 1280 1280
Tread Rear (mm) 1290 1290 1290 1290 1290 1290
Wheelbase (mm) 2350 2350 2350 2350 2350 2350
Minimum Turning Radius (m) 4.5 4.5 4.5 4.5 4.5 4.5
*Ambulance shell is incompletely built vehicle, for fabrication of Type B Road Ambulance, with recommended seating capacity of 3 Persons + 1 Patient.
Engine(Petrol and CNG)
  5 Seater Standard 5 Seater AC 5 Seater AC CNG 7 Seater Standard Ambulance Ambulance Shell*
Engine Type K12N K12N K12N K12N K12N K12N
Engine Displacement(CC) 1197 1197 1197 1197 1197 1197
Max. Output(kw/rpm) 59.4/6000
(Gasoline)		 59.4/6000
(Gasoline)		 59.4/6000
(Gasoline)
52.7/6000
(CNG)		 59.4/6000
(Gasoline)		 59.4/6000
(Petrol)		 59.4/6000
(Petrol)
Max. Torque(Nm/rpm) 104.4/3000
(Gasoline)		 104.4/3000
(Gasoline)		 104.4/3000
(Gasoline)
95/3000
(CNG)		 104.4/3000
(Gasoline)		 104.4/3000
(Petrol)		 104.4/3000
(Petrol)
Tank Capacity 32 L 32 L 65 L 32 L 32 L 32 L
*Ambulance shell is incompletely built vehicle, for fabrication of Type B Road Ambulance, with recommended seating capacity of 3 Persons + 1 Patient.
Transmission
  5 Seater Standard 5 Seater AC 5 Seater AC CNG 7 Seater Standard Ambulance Ambulance Shell*
Petrol & CNG 5MT 5MT 5MT 5MT 5MT 5MT
*Ambulance shell is incompletely built vehicle, for fabrication of Type B Road Ambulance, with recommended seating capacity of 3 Persons + 1 Patient.
Brake/Chassis
  5 Seater Standard 5 Seater AC 5 Seater AC CNG 7 Seater Standard Ambulance Ambulance Shell*
Brake Front Disc Disc Disc Disc Disc Disc
Brake Rear Drum Drum Drum Drum Drum Drum
Front Suspension MacPherson Strut MacPherson Strut MacPherson Strut MacPherson Strut MacPherson Strut MacPherson Strut
Tyre Size 155R13C 8PR 155R13C 8PR 155R13C 8PR 155R13C 8PR 155R13C 8PR 155R13C 8PR
*Ambulance shell is incompletely built vehicle, for fabrication of Type B Road Ambulance, with recommended seating capacity of 3 Persons + 1 Patient.
Ertiga
  • INFOTAINMENT SYSTEM
  • COMFORT & CONVENIENCE
  • EXTERIOR
  • INSTRUMENT CLUSTER
  • INTERIOR
  • SAFETY AND SECURITY
  • **SUZUKI CONNECT
INFOTAINMENT SYSTEM
LXi MT VXi MT VXi AT VXi CNG Zxi MT ZXi AT ZXi CNG ZXi+ MT ZXi+ AT
17.78cm SmartPlay Pro Touch Screen Infotainment System
17.78cm SmartPlay Studio Touch Screen Infotainment System
Premium Sound System ARKAMYS
(Surround Sense)		 ARKAMYS
(Surround Sense)
Android Auto* & Apple Can Play~ Wireless Wireless
Audio System with Electrostatic Touch Buttons
Bluetooth Connectivity
Speakers(4)
Tweeters(2)
USB and AUX Connectivity USB Only USB Only USB Only USB Only USB Only
Steering Mounted Audio Control
Steering Mounted Calling Control
* Android Auto™ extends the Android platform into the car in a way that's purpose-built for driving. It is designed to minimise distraction so you can focus on driving with Google™ services like Google Maps™ and Google Search™. Get the Android Auto app on Google Play™. Android Auto is available in the countries listed at the following link:https://www.android.com/auto/#hit-the-road. Most phones with Android 5.0+ work with Android Auto: https://support.google.com/androidauto/#6140477. Android, Android Auto, Google, Google Play and other marks are trademarks of Google Inc. Image used are for illustration purposes only.
~ Apple and iPhone are trademarks of Apple Inc. registered in the U.S. and other countries. Apple CarPlay is a trademark of Apple Inc., Apple CarPlay is available in the countries listed in the following link: http://www.apple.com/ios/feature-availability/#applecarplay-applecarplay. Apple CarPlay is compatible with the iPhone models listed in the following link:http://www/apple.com/ios/carplay
COMFORT & CONVENIENCE
LXi MT VXi MT VXi AT VXi CNG Zxi MT ZXi AT ZXi CNG ZXi+ MT ZXi+ AT
Engine Push Start/Stop with Smart Key
Manual AC (Front)
Auto AC (Front)
2nd Row Roof Mounted AC with 3 Stage Speed Control
Air Cooled Twin Cup Holders (Console)
Rear Defogger
Remote Keyless Entry (Smart Key) (Smart Key) (Smart Key) (Smart Key) (Smart Key)
Power Socket (12V) Front Row with Smartphone Storage Space
Power Socket (12V) 2nd Row
2nd Row Smart Phone Storage Space
Power Socket (12V) 3rd Row
Power Windows (Fr/Rr) with Dr. Side Auto Down Functions
Auto Window Up (Dr. Side with anti-pinch)
Day & Night Adjustable IRVM
Power & Tilt Steering
Electrically Adjustable ORVMs
Electrically Foldable ORVMs
Retractable ORVMs (Key Operated)
Bottle Holders (in each row)
Coin/Ticket Holder (Driver Side)
Cabin Lamp (Fr.+Rr.)
Cruise Control
Paddle Shifters (AT) (AT) (AT) (AT) (AT) (AT) (AT) (AT)
Foot Rest
Auto Headlamps with Follow Me Home/Lead me to Vehicle Feature
EXTERIOR
LXi MT VXi MT VXi AT VXi CNG Zxi MT ZXi AT ZXi CNG ZXi+ MT ZXi+ AT
Projector Headlamps (Halogen)
3D Origami Style LED Tail Lamps
Dynamic Chrome Winged Front Grille Painted Chrome Chrome Chrome Chrome Chrome Chrome Chrome Chrome
Floating Type Roof Design in Rear
Full Wheel Caps
Machined Two-tone Alloy Wheels
Turn Signal Lamp Integrated in ORVMs
New Back Door Garnish with Chrome Insert
Rear Wiper & Washer
Body Coloured Door Handles
Chrome Plated Door Handles
Body Coloured ORVMs
INSTRUMENT CLUSTER
LXi MT VXi MT VXi AT VXi CNG Zxi MT ZXi AT ZXi CNG ZXi+ MT ZXi+ AT
MID With Coloured TFT
Tachometer
Gear Shift Indicator (MT)
Digital Clock
Outside Temperature Gauge
Fuel Consumption (Instantaneous and Avg)##
Dedicated CNG Fuel Gauge (CNG) (CNG) (CNG) (CNG) (CNG) (CNG)
Total CNG Mode Time (CNG) (CNG) (CNG) (CNG) (CNG) (CNG)
Distance to Empty##
Headlamp On Warning
Door Ajar Warning Lamp
##Except CNG.
INTERIORS
LXi MT VXi MT VXi AT VXi CNG Zxi MT ZXi AT ZXi CNG ZXi+ MT ZXi+ AT
Sculpted Dashboard with Metallic Teak - Wooden Finish
Metallic Teak-Wooden Finish on Door Trims (Fr.)
Premium Dual Tone Interiors
Height Adjustable Driver Seat
2nd Row 60:40 Split Seats with One Touch Recline & Slide
3rd Row 50:50 Split Seats with Recline function
Flexible luggage space with Flat Fold (3rd Row)
Plush Dual-Tone Seat Fabric
Fr. Seat Back Pockets Co-driver Co-driver Co-driver
Sliding Armrest with Utility Box (Front Row)
2nd Row Center Armrest
Leather Wrapped Steering Wheel with Metallic Teak-Wooden Finish
Adjustable Headrest (All Rows)
Split Type Luggage Board (Expect CNG) (Expect CNG) (Expect CNG) (Expect CNG) (Expect CNG) (Expect CNG)
Driver Side Sunvisor with Ticket Holder
Passenger Side Sunvisor with Vanity Mirror
Dazzle Chrome Tipped Parking Brake Lever
Gear Shift Knob with Dazzle Chrome Finish
SAFETY AND SECURITY
LXi MT VXi MT VXi AT VXi CNG Zxi MT ZXi AT ZXi CNG ZXi+ MT ZXi+ AT
Suzuki Heartect Platform
Dual Front Airbags
Fr.Seat Side Airbags
ABS with EBD and Brake Assist
Engine Immobilizer
ESP
Hill Hold
ISOFIX Child Seat Anchorages (2nd Row Seats)
Front Seat Belts with Pre-tensioner & Force Limiters (Dr.+Co-Dr.)
Seat Belt Reminder Lamp and Buzzer (All Passengers)^^^
Front Seat Belt Height Adjuster
High Speed Alert System^
Speed Sensitive Auto Door Lock
Security Alarm
Rear Parking Sensors
Rear Parking Camera
Central Locking
Front Fog Lamps
^^^ Seatbelt reminder comes on unless all rear passengers' seat belts are fastened irrespective of the presence or absence of passenger. Seat belt reminder lamp will continue to glow in the instrument cluster till seat belt is buckled, whereas buzzer will beep for approximately 95 secs or till the passenger buckles the seatbelt (whichever is the earliest.)
^ The speed alert system gives audible warning for alert of over-speed to driver. When vehicle speed exceeds about 80 km/h, primary level warning with two beeps will sound every minute. When the vehicle speed exceeds about 120 km/h, secondary level warning with continuous beeps will sound. If the vehicle speed is slowed down to about 118 km/h, primary warning will resume. If the vehicle is slowed down to about 78 km/h, speed alert warning will stop. This buzzer does not indicate any malfunction in vehicle.
**SUZUKI CONNECT
LXi MT VXi MT VXi AT VXi CNG Zxi MT ZXi AT ZXi CNG ZXi+ MT ZXi+ AT
Safety and Security
Emergency Alerts
Breakdown notification
Stolen Vehicle Notification and Tracking
Tow Away Alert and Tracking
Geo-Fence
Time Fence
Valet Alert
Trips and Driving Behaviour
Trip Summary
Driving Behaviour
Share Trip History
Area Guidance Around Destination
Vehicle location Sharing
Alerts and Notification
Overspeed
Seatbelt
AC Idling
Trip (Start &End)
Low Fuel & Low Range##
Dashboard View
Remote functions
Door Lock/Cancel Lock
Hazard Light ON/OFF
Headlight OFF
Alarm
Immobilizer Request
Battery Health
Smartwatch Connectivity
Suzuki Connect skill for Amazon, Alexa****
Remote Ac (AT) (AT) (AT) (AT) (AT)
**Suzuki Connect (available through phone/smartwatch/Suzuki connect skill for Amazon Alexa).
##Except CNG.
****Amazon, Alexa and all related marks are trademarks of Amazon.com, Inc. or its affiliates. This is to clarify that LXi (O), VXi (O) & ZXi (O) are same variants with same features as LXi , VXi & ZXi.
  • Dimensions
  • Engine
  • Drive & Transmission
  • Brake
  • Suspension
  • New Technology
  • Weight
Dimension
  LXi MT VXi MT VXi AT VXi MT CNG Zxi MT ZXi AT ZXi MT CNG ZXi+ MT ZXi+ AT
Length (mm) 4395 4395 4395 4395 4395 4395 4395 4395 4395
Width (mm) 1735 1735 1735 1735 1735 1735 1735 1735 1735
Height (mm)(Unladen) 1690 1690 1690 1690 1690 1690 1690 1690 1690
Wheelbase (mm) 2740 2740 2740 2740 2740 2740 2740 2740 2740
Turning Radius (m) 5.2 5.2 5.2 5.2 5.2 5.2 5.2 5.2 5.2
Seating Capacity 7 7 7 7 7 7 7 7 7
Engine
  LXi MT VXi MT VXi AT VXi MT CNG Zxi MT ZXi AT ZXi MT CNG ZXi+ MT ZXi+ AT
Type K15C SMART HYBRID K15C SMART HYBRID K15C SMART HYBRID K15C K15C SMART HYBRID K15C SMART HYBRID K15C K15C SMART HYBRID K15C SMART HYBRID
Capacity (cc) 1462 1462 1462 1462 1462 1462 1462 1462 1462
Compression Ratio 12 ± 0.3 12 ± 0.3 12 ± 0.3 12 ± 0.3 12 ± 0.3 12 ± 0.3 12 ± 0.3 12 ± 0.3 12 ± 0.3
Power (KW@RPM) 75.8@6000 75.8@6000 75.8@6000 74.0 @ 6000 (Gasoline Mode)
64.6 @ 5500 (CNG Mode)		 75.8@6000 75.8@6000 74.0 @ 6000 (Gasoline Mode)
64.6 @ 5500 (CNG Mode)		 75.8@6000 75.8@6000
Torque(Nm@RPM) 136.8@4400 136.8@4400 136.8@4400 136.0 @ 4400 (Gasoline Mode)
121.5 @ 4200 (CNG Mode)		 136.8@4400 136.8@4400 136.0 @ 4400 (Gasoline Mode)
121.5 @ 4200 (CNG Mode)		 136.8@4400 136.8@4400
Emission Type BS VI BS VI BS VI BS VI BS VI BS VI BS VI BS VI BS VI
Fuel Tank Capacity (L) 45 45 45 Petrol:45
CNG: 60 (Water Equivalent)		 45 45 Petrol:45
CNG: 60 (Water Equivalent)		 45 45
Drive & Transmission
  LXi MT VXi MT VXi AT VXi MT CNG Zxi MT ZXi AT ZXi MT CNG ZXi+ MT ZXi+ AT
Drive 2WD,FF 2WD,FF 2WD,FF 2WD,FF 2WD,FF 2WD,FF 2WD,FF 2WD,FF 2WD,FF
Transmission 5MT/6AT 5MT/6AT 5MT/6AT 5MT 5MT/6AT 5MT/6AT 5MT 5MT/6AT 5MT/6AT
Break
  LXi MT VXi MT VXi AT VXi MT CNG Zxi MT ZXi AT ZXi MT CNG ZXi+ MT ZXi+ AT
Front Disc Disc Disc Disc Disc Disc Disc Disc Disc
Rear Drum Drum Drum Drum Drum Drum Drum Drum Drum
Suspension
  LXi MT VXi MT VXi AT VXi MT CNG Zxi MT ZXi AT ZXi MT CNG ZXi+ MT ZXi+ AT
Front Mac Pherson Strut & Coil Spring Mac Pherson Strut & Coil Spring Mac Pherson Strut & Coil Spring Mac Pherson Strut & Coil Spring Mac Pherson Strut & Coil Spring Mac Pherson Strut & Coil Spring Mac Pherson Strut & Coil Spring Mac Pherson Strut & Coil Spring Mac Pherson Strut & Coil Spring
Rear Torsion Beam & Coil Spring Torsion Beam & Coil Spring Torsion Beam & Coil Spring Torsion Beam & Coil Spring Torsion Beam & Coil Spring Torsion Beam & Coil Spring Torsion Beam & Coil Spring Torsion Beam & Coil Spring Torsion Beam & Coil Spring
Tyre Size 185/65 R15 185/65 R15 185/65 R15 185/65 R15 185/65 R15 185/65 R15 185/65 R15 185/65 R15 185/65 R15
New Technology
  LXi MT VXi MT VXi AT VXi MT CNG Zxi MT ZXi AT ZXi MT CNG ZXi+ MT ZXi+ AT
Idle Start Stop
Brake Energy Regeneration
Torque Assist
Weight
  LXi MT VXi MT VXi AT VXi MT CNG Zxi MT ZXi AT ZXi MT CNG ZXi+ MT ZXi+ AT
Kerb Weight (kg) 1150-1205 1150-1205 1150-1205 1250-1255 1150-1205 1150-1205 1250-1255 1150-1205 1150-1205
Gross Vehicle Weight (kg) 1760(MT),1785(AT) 1760(MT),1785(AT) 1760(MT),1785(AT) 1820 1760(MT),1785(AT) 1760(MT),1785(AT) 1820 1760(MT),1785(AT) 1760(MT),1785(AT)
Swift
  • Exteriors
  • Interiors
  • Safety & Security
  • Audio & Entertainment
  • Comfort & Convenience
  • Colour Variants
Exteriors
  Lxi 5MT Vxi 5MT Vxi 5AMT Zxi 5MT Zxi 5AMT Zxi+ 5MT Zxi+ 5AMT Vxi CNG 5MT Zxi CNG 5MT
LED Projector Headlamps
LED Daylight Running Lamps
LED Rear Combination Lamp
LED High Mounted Stop Lamp
Wheels (Steel/Alloy/Precision Cut Alloy) Steel Steel Steel Alloy Alloy Precision Cut Alloy Precision Cut Alloy Steel Alloy
Full Wheel Covers
Side Turn Indicators on ORVMs
Body Coloured ORVMs  (Roof Colour in Dual Tone)  (Roof Colour in Dual Tone)
Body Coloured Bumpers
Body Coloured Outside Front Door Handles
Interiors
  Lxi 5MT Vxi 5MT Vxi 5AMT Zxi 5MT Zxi 5AMT Zxi+ 5MT Zxi+ 5AMT Vxi CNG 5MT Zxi CNG 5MT
Leather^ Wrapped Steering Wheel
Silver Ornament on Front Door Armrest
Outside Temperature Display (AMT only) (AMT only)
Co-Driver Side Sunvisor with Vanity Mirror
Driver Side Sunvisor with Ticket Holder
Front Seat Back Pocket (Co-Driver side)
Chrome Parking Brake Lever Tip
IP Ornament
Gear Shift Knob in Piano Black Finish
Chrome Inside Door Handles
Tachometer
Front Dome Lamp
Multi-Information Display  (Coloured)  (Coloured)
^Certain parts of the leather upholstery contain man-made material.
Safety & Security
  Lxi 5MT Vxi 5MT Vxi 5AMT Zxi 5MT Zxi 5AMT Zxi+ 5MT Zxi+ 5AMT Vxi CNG 5MT Zxi CNG 5MT
Dual Front Airbags##
ABS with EBD and Brake Assist
ESP with Hill Hold Assist (AMT only) (AMT only) (AMT only) (AMT only) (AMT only) (AMT only)
Reverse Parking Sensors
Reverse Parking Camera
Security Alarm System
Pinch Guard Power Window (Driver Side)
Front Seat Belts with Pre-Tensioner and Force Limiter
Pedestrian Protection Compliance
IsoFix with Child Seat Anchorages
Front Fog Lamps
Speed Sensitive Automatic Door Lock
Seat Belt Reminder & Buzzer (Driver & Co-Driver Side)
Day and Night Adjustable IRVM
Engine Immobilizer
High Speed Alert System*
##For details on functioning of safety features, including air bag, kindly refer to the Owner's Manual.
*The speed alert system gives audible warning for alert of over-speed to driver. When vehicle speed exceeds about 80 km/h, primary level warning with two beeps will sound every minute. When the vehicle speed exceeds about 120 km/h, secondary level warning with continuous beeps will sound. If the vehicle speed is slowed down to about 118 km/h, primary warning will resume. If the vehicle is slowed down to about 78 km/h, speed alert warning will stop. This buzzer does not indicate any malfunction in vehicle.
Audio & Entertainment
  Lxi 5MT Vxi 5MT Vxi 5AMT Zxi 5MT Zxi 5AMT Zxi+ 5MT Zxi+ 5AMT Vxi CNG 5MT Zxi CNG 5MT
17.78 cm Touchscreen Smartplay Studio
Navigation System with Live Traffic Update(through Smartplay Studio App)
AHA Platform (through Smartplay Studio App)
Voice Command
Smartphone Connect (Android Auto and Apple CarPlay)
Remote Control (through Smartplay Studio App)
All New Feather Touch Audio System
Steering Mounted Audio & Calling Controls
AUX-in, USB & Bluetooth Connectivity
Door Speakers (4)
Tweeters (2)
Roof Antenna
Comfort & Convenience
  Lxi 5MT Vxi 5MT Vxi 5AMT Zxi 5MT Zxi 5AMT Zxi+ 5MT Zxi+ 5AMT Vxi CNG 5MT Zxi CNG 5MT
Cruise Control
Engine Push Start-Stop Button with Smart Key
Auto Headlamps(lead me to vehicle/follow me home)
Automatic Climate Control
Manual Air Conditioner with Heater
Remote Keyless Entry System
Central Door Locking
Auto Down Power Window (Driver Side)
Auto Up Power Window (Driver Side)
Power Windows (Front + Rear)
Power & Tilt Steering
Manually Adjustable ORVMs
Electrically Adjustable ORVMs
Electrically Foldable ORVMs (Key Sync) (Key Sync)
Electromagnetic Back Door Opener
Rear Defogger
Rear Wiper & Washer
Adjustable Front Seat Headrests
Adjustable Rear Seat Headrests
Height Adjustable Driver Seat
Gear Shift Indicator (MT only) (MT only) (MT only) (MT only) (MT only) (MT only)
Gear Position Indicator (AMT only) (AMT only) (AMT only) (AMT only) (AMT only) (AMT only)
Driver Side Foot Rest (AMT only) (AMT only) (AMT only) (AMT only) (AMT only) (AMT only)
60:40 Split Rear Seat
Rear Parcel Shelf
Luggage Room Lamp
Front Accessory Socket
Low Fuel Warning Lamp
Door Ajar Warning Lamp
Headlamp On Reminder
Colour Variants
  Lxi 5MT Vxi 5MT Vxi 5AMT Zxi 5MT Zxi 5AMT Zxi+ 5MT Zxi+ 5AMT Vxi CNG 5MT Zxi CNG 5MT
Solid Fire Red with Pearl Midnight Black Roof
Pearl Metallic Midnight Blue with Pearl Arctic White Roof
Pearl Arctic White with Pearl Midnight Black Roof
Solid Fire Red
Pearl Metallic Midnight Blue
Pearl Arctic White
Pearl Metallic Lucent Orange
Metallic Magma Grey
Metallic Silky Silver
  • Seating Capacity
  • Engine
  • Transmission
  • Dimensions
  • Weight
  • Brakes
  • Steering
  • Suspension
  • Tyre Size
  • Fuel Tank
Seating Capacity
  Lxi 5MT Vxi 5MT Vxi 5AMT Zxi 5MT Zxi 5AMT Zxi+ 5MT Zxi+ 5AMT Vxi CNG 5MT Zxi CNG 5MT
Capacity 5 5 5 5 5 5 5 5 5
Engine
  Lxi 5MT Vxi 5MT Vxi 5AMT Zxi 5MT Zxi 5AMT Zxi+ 5MT Zxi+ 5AMT Vxi CNG 5MT Zxi CNG 5MT
Engine Type Advanced K Series Dual Jet, Dual VVT Engine Advanced K Series Dual Jet, Dual VVT Engine Advanced K Series Dual Jet, Dual VVT Engine Advanced K Series Dual Jet, Dual VVT Engine Advanced K Series Dual Jet, Dual VVT Engine Advanced K Series Dual Jet, Dual VVT Engine Advanced K Series Dual Jet, Dual VVT Engine Advanced K Series Dual Jet, Dual VVT Engine Advanced K Series Dual Jet, Dual VVT Engine
Fuel Type Gasoline Gasoline Gasoline Gasoline Gasoline Gasoline Gasoline Gasoline & CNG Gasoline & CNG
Emission Type BS VI BS VI BS VI BS VI BS VI BS VI BS VI BS VI BS VI
Capacity 1197cc 1197cc 1197cc 1197cc 1197cc 1197cc 1197cc 1197cc 1197cc
Number of Cylinders 4 4 4 4 4 4 4 4 4
Max Power (kW @ rpm)(PS@rpm) 66 kW @ 6000 rpm
89.73 PS @6000 rpm 		66 kW @ 6000 rpm
89.73 PS @6000 rpm 		66 kW @ 6000 rpm
89.73 PS @6000 rpm 		66 kW @ 6000 rpm
89.73 PS @6000 rpm 		66 kW @ 6000 rpm
89.73 PS @6000 rpm 		66 kW @ 6000 rpm
89.73 PS @6000 rpm 		66 kW @ 6000 rpm
89.73 PS @6000 rpm 		57 kW @ 6000 rpm
77.49 PS @6000 rpm 		57 kW @ 6000 rpm
77.49 PS @6000 rpm
Max Torque (Nm @ rpm) 113@4400 113@4400 113@4400 113@4400 113@4400 113@4400 113@4400 98.5@4300 98.5@4300
Transmission
  Lxi 5MT Vxi 5MT Vxi 5AMT Zxi 5MT Zxi 5AMT Zxi+ 5MT Zxi+ 5AMT Vxi CNG 5MT Zxi CNG 5MT
Type 5MT/5AMT 5MT/5AMT 5MT/5AMT 5MT/5AMT 5MT/5AMT 5MT/5AMT 5MT/5AMT 5MT 5MT
Dismensions
  Lxi 5MT Vxi 5MT Vxi 5AMT Zxi 5MT Zxi 5AMT Zxi+ 5MT Zxi+ 5AMT Vxi CNG 5MT Zxi CNG 5MT
Length (mm) 3845 3845 3845 3845 3845 3845 3845 3845 3845
Width (mm) 1735 1735 1735 1735 1735 1735 1735 1735 1735
Height (mm) 1530 (Unladen) 1530 (Unladen) 1530 (Unladen) 1530 (Unladen) 1530 (Unladen) 1530 (Unladen) 1530 (Unladen) 1530 (Unladen) 1530 (Unladen)
Wheelbase (mm) 2450 2450 2450 2450 2450 2450 2450 2450 2450
Track, Front (mm) 1530(165/80R14),
1520(185/65R15)		 1530(165/80R14),
1520(185/65R15)		 1530(165/80R14),
1520(185/65R15)		 1530(165/80R14),
1520(185/65R15)		 1530(165/80R14),
1520(185/65R15)		 1530(165/80R14),
1520(185/65R15)		 1530(165/80R14),
1520(185/65R15)		 1530(165/80R14),
1520(185/65R15)		 1530(165/80R14),
1520(185/65R15)
Track, Rear (mm) 1530(165/80R14),
1520(185/65R15)		 1530(165/80R14),
1520(185/65R15)		 1530(165/80R14),
1520(185/65R15)		 1530(165/80R14),
1520(185/65R15)		 1530(165/80R14),
1520(185/65R15)		 1530(165/80R14),
1520(185/65R15)		 1530(165/80R14),
1520(185/65R15)		 1530(165/80R14),
1520(185/65R15)		 1530(165/80R14),
1520(185/65R15)
Boot Space (L) 268 268 268 268 268 268 268
Weight
  Lxi 5MT Vxi 5MT Vxi 5AMT Zxi 5MT Zxi 5AMT Zxi+ 5MT Zxi+ 5AMT Vxi CNG 5MT Zxi CNG 5MT
Kerb Weight (Kg) 875-905 875-905 875-905 875-905 875-905 875-905 875-905 980-985 980-985
Gross Vehicle Weight (Kg) 1335 1335 1335 1335 1335 1335 1335 1405 1405
Brakes
  Lxi 5MT Vxi 5MT Vxi 5AMT Zxi 5MT Zxi 5AMT Zxi+ 5MT Zxi+ 5AMT Vxi CNG 5MT Zxi CNG 5MT
Front Disc Disc Disc Disc Disc Disc Disc Disc Disc
Rear Drum Drum Drum Drum Drum Drum Drum Drum Drum
Steering
  Lxi 5MT Vxi 5MT Vxi 5AMT Zxi 5MT Zxi 5AMT Zxi+ 5MT Zxi+ 5AMT Vxi CNG 5MT Zxi CNG 5MT
Power Steering Type Electric Electric Electric Electric Electric Electric Electric Electric Electric
Turning Radius(m) 4.8 4.8 4.8 4.8 4.8 4.8 4.8 4.8 4.8
Suspension
  Lxi 5MT Vxi 5MT Vxi 5AMT Zxi 5MT Zxi 5AMT Zxi+ 5MT Zxi+ 5AMT Vxi CNG 5MT Zxi CNG 5MT
Front Mac Pherson Strut Mac Pherson Strut Mac Pherson Strut Mac Pherson Strut Mac Pherson Strut Mac Pherson Strut Mac Pherson Strut Mac Pherson Strut Mac Pherson Strut
Rear Torsion Beam Torsion Beam Torsion Beam Torsion Beam Torsion Beam Torsion Beam Torsion Beam Torsion Beam Torsion Beam
Tyre Size
  Lxi 5MT Vxi 5MT Vxi 5AMT Zxi 5MT Zxi 5AMT Zxi+ 5MT Zxi+ 5AMT Vxi CNG 5MT Zxi CNG 5MT
Steel 165/80 R14 165/80 R14 165/80 R14 Vxi : 165/80 R14
Alloy** 185/65 R15 185/65 R15 185/65 R15 185/65 R15 Zxi: 185/65 R15
**Spare wheel material is steel and spare tyre size is 165/80R14.
Feul Tank
  Lxi 5MT Vxi 5MT Vxi 5AMT Zxi 5MT Zxi 5AMT Zxi+ 5MT Zxi+ 5AMT Vxi CNG 5MT Zxi CNG 5MT
Fuel Tank Capacity (L) 37 37 37 37 37 37 37 Gasoline: 37 L
CNG: 55 L(water filling capacity) 		Gasoline: 37 L
CNG: 55 L(water filling capacity)
S-Presso
  • Interiors
  • Comfort
  • Infotainment System
  • Safety and Security
  • Exterior
  • Instrument Cluster
Interiors
  Std MT LXi MT LXi CNG MT VXi MT VXi(O) AGS VXi CNG MT VXi+ MT VXi+(O) AGS
Dynamic Centre Console
High Seating for commanding drive view
Coloured Centre Garnish ** **
Front Cabin Lamp (3 positions)
Sunvisor (Dr+Co. Dr)
**Orange in solid sizzle orange body colour & Silver in the remaining 5 body colours.
Comfort
  Std MT LXi MT LXi CNG MT VXi MT VXi(O) AGS VXi CNG MT VXi+ MT VXi+(O) AGS
AC with Heater
Power Steering
Accessory Socket
Front Console Utility Space
1L Bottle Holders with Map Pockets (Front doors)
Rear Console Utility Space
Co-Driver Side Utility Space
Reclining & Front Sliding Seats
Remote keyless entry
Rear Parcel Tray
Front Power Windows
Internally Adjustable ORVMs (Dr+Co. Dr)
Electrically Adjustable ORVMs (Dr+Co. Dr)
Idle Start Stop (ISS) Petrol
Variant Only		 Petrol
Variant Only		 Petrol
Variant Only		 Petrol
Variant Only		 Petrol
Variant Only
Infotainment System
  Std MT LXi MT LXi CNG MT VXi MT VXi(O) AGS VXi CNG MT VXi+ MT VXi+(O) AGS
SmartPlay Studio - 17.78 cm Touch screen Infotainment System
SmartPlay Dock
Apple Car Play and Android Auto###
Bluetooth
Speakers 2 2 2 2 2
USB connectivity/Aux
Steering-Mounted Audio & Voice Control
HEARTECT Platform
###Apple and iPhone are trademarks of Apple Inc. registered in the U.S. and other countries. Apple CarPlay is a trademark of Apple Inc., Apple CarPlay is available in the countries listed in the following link: http://www.apple.com/ios/feature-availability/#applecarplay-applecarplay. Apple CarPlay is compatible with the iPhone models listed in the following link: http://www/apple.com/ios/carplay. Android Auto™ extends the Android platform into the car in a way that's purpose-built for driving. It is designed to minimise distraction so you can focus on driving with Google™ services like Google Map™ and Google Search™. Get the Android Auto app on Google Play™. Android Auto is available in the countries listed at the following link: https://www.android.com/auto/#hit-the-road. Most phones with Android 5.0+ work with Android Auto: https://support.google.com/androidauto/#6140477. Android, Android Auto, Google, Google Play and other marks are trademarks of Google Inc.
Safety and Security
  Std MT LXi MT LXi CNG MT VXi MT VXi(O) AGS VXi CNG MT VXi+ MT VXi+(O) AGS
Cabin Air Filter
ESP with Hill Hold AGS Only AGS Only AGS Only AGS Only AGS Only
ABS with EBD
Seat Belt Reminder with Buzzer Front + Rear seat^^
Rear Seat Belt Center (2-Point Static) Petrol variant only Petrol variant only Petrol variant only Petrol variant only Petrol variant only
Rear Seat Belt Outboard (3-Point) (Static) (Static) (Static) (ELR) (ELR) (ELR) (ELR) (ELR)
Reverse Parking Sensors
Speed Alert System^
Pedestrian Protection
Child Proof Rear Door Lock
Speed Sensitive Auto Door Lock
Central Door Locking
Dual Airbag#
Front Seatbelt Pre-tensioner and Force Limiter
Low Fuel Warning (Petrol Fuel) SmartPlay Dock SmartPlay Dock SmartPlay Dock SmartPlay Studio SmartPlay Studio
Door Ajar Warning SmartPlay Dock SmartPlay Dock SmartPlay Dock SmartPlay Studio SmartPlay Studio
Parking Brake Warning
^^Seat belt reminder comes on unless all rear passenger's seat belts are fastened irrespective of the presence or absence of passenger.
^The speed alert system gives audible warning for alert of over-speed to driver. When the vehicle speed exceeds about 80km/h, primary level warning with two beeps will sound every minute. When the vehicle speed exceeds about 120km/h, secondary level warning with continuous beeps will sound. If the vehicle speed is slowed down to about 118km/h, primary warning will resume. If the vehicle is slowed down to 78km/h, speed alert warning will stop. This buzzer does not indicate any malfunction in vehicle.
#For details on the functioning of safety features including airbags, kindly refer to the Owners Manual.
Exterior
  Std MT LXi MT LXi CNG MT VXi MT VXi(O) AGS VXi CNG MT VXi+ MT VXi+(O) AGS
SUV Inspired Bold Front Fascia
Twin Chamber Headlamps
Roof Antenna
Signature C shaped Tail Lamps
B-Pillar Black Out Tape
Side Body Cladding
Body Coloured Bumpers
Body Coloured ORVMs
Body Coloured Outside Door Handles
Full Wheel Covers
Instrument Cluster
  Std MT LXi MT LXi CNG MT VXi MT VXi(O) AGS VXi CNG MT VXi+ MT VXi+(O) AGS
Digital Display in the Instrument Cluster
Fuel Consumption (Instantaneous & Average)
Headlamp On Warning
Gear Shift Indicator (MT Only) Petrol
Variant Only		 Petrol
Variant Only		 Petrol
Variant Only
Gear Position Indicator AGS Only AGS Only AGS Only AGS Only AGS Only
Distance to empty
  • Dimensions
  • Engine
  • Emission Type
  • Drive & Transmission
  • Brake
  • Suspension
  • Weight
Dimensions
  Std MT LXi MT LXi CNG MT VXi MT VXi(O) AGS VXi CNG MT VXi+ MT VXi+(O) AGS
Length (mm) 3565 3565 3565 3565 3565 3565 3565 3565
Width (mm) 1520 1520 1520 1520 1520 1520 1520 1520
Height (mm) 1553 1553 1553 1567 1567 1567 1567 1567
Wheelbase (mm) 2380 2380 2380 2380 2380 2380 2380 2380
Turning Radius (m) 4.5 4.5 4.5 4.5 4.5 4.5 4.5 4.5
Seating Capacity 5 5 4 5 5 4 5 5
Engine
  Std MT LXi MT LXi CNG MT VXi MT VXi(O) AGS VXi CNG MT VXi+ MT VXi+(O) AGS
Type K10C K10C K1OC CNG K10C K10C K1OC CNG K10C K10C
Capacity (cc) 998 998 998 998 998 998 998 998
Power 49 kW(66.621PS) @
5500 rpm		 49 kW(66.621PS) @
5500 rpm		 41.7 kW (56.696PS) @
5300 rpm (CNG Mode)
48 kW (65.261PS) @
5500 rpm (Petrol Mode) 		49 kW(66.621PS) @
5500 rpm		 49 kW(66.621PS) @
5500 rpm		 41.7 kW (56.696PS) @
5300 rpm (CNG Mode)
48 kW (65.261PS) @
5500 rpm (Petrol Mode) 		49 kW(66.621PS) @
5500 rpm		 49 kW(66.621PS) @
5500 rpm
Torque 89 Nm @
3500 rpm		 89 Nm @
3500 rpm		 82.1 Nm @
3400 rpm (CNG Mode)
89 Nm @
3500 rpm (Petrol Mode) 		89 Nm @
3500 rpm		 89 Nm @
3500 rpm		 82.1 Nm @
3400 rpm (CNG Mode)
89 Nm @
3500 rpm (Petrol Mode) 		89 Nm @
3500 rpm		 89 Nm @
3500 rpm
Fuel Type Petrol Petrol Petrol+CNG Petrol Petrol Petrol+CNG Petrol Petrol
Fuel Tank Capacity (L) 27 27 27 (Petrol Mode)
55 (CNG Mode)
(Equivalent Water Filling Capacity) 		27 27 27 (Petrol Mode)
55 (CNG Mode)
(Equivalent Water Filling Capacity) 		27 27
Emission Type
  Std MT LXi MT LXi CNG MT VXi MT VXi(O) AGS VXi CNG MT VXi+ MT VXi+(O) AGS
Type BS VI BS VI BS VI BS VI BS VI BS VI BS VI BS VI
Drive & Transmission
  Std MT LXi MT LXi CNG MT VXi MT VXi(O) AGS VXi CNG MT VXi+ MT VXi+(O) AGS
Drive 2WD, FF 2WD, FF 2WD, FF 2WD, FF 2WD, FF 2WD, FF 2WD, FF 2WD, FF
Transmission 5MT/ AGS 5MT/ AGS 5MT 5MT/ AGS 5MT/ AGS 5MT 5MT/ AGS 5MT/ AGS
Brake
  Std MT LXi MT LXi CNG MT VXi MT VXi(O) AGS VXi CNG MT VXi+ MT VXi+(O) AGS
Front Ventilated Disc Ventilated Disc Ventilated Disc Ventilated Disc Ventilated Disc Ventilated Disc Ventilated Disc Ventilated Disc
Rear Drum Drum Drum Drum Drum Drum Drum Drum
Suspension
  Std MT LXi MT LXi CNG MT VXi MT VXi(O) AGS VXi CNG MT VXi+ MT VXi+(O) AGS
Front MacPherson Strut with Coil Spring MacPherson Strut with Coil Spring Mac Pherson Strut with
Coil Spring and Stabilizer Bar 		MacPherson Strut with Coil Spring MacPherson Strut with Coil Spring Mac Pherson Strut with
Coil Spring and Stabilizer Bar 		MacPherson Strut with Coil Spring MacPherson Strut with Coil Spring
Rear Torsion Beam with Coil Spring Torsion Beam with Coil Spring Torsion Beam with Coil Spring Torsion Beam with Coil Spring Torsion Beam with Coil Spring Torsion Beam with Coil Spring Torsion Beam with Coil Spring Torsion Beam with Coil Spring
Tyre Size 145/80 R13 145/80 R13 145/80 R13 165/70 R14 165/70 R14 165/70 R14 165/70 R14 165/70 R14
Weight
  Std MT LXi MT LXi CNG MT VXi MT VXi(O) AGS VXi CNG MT VXi+ MT VXi+(O) AGS
Kerb Weight (kg) 736-775 736-775 834-854 736-775 736-775 834-854 736-775 736-775
Maximum GVW (kg) 1170 1170 1170 1170 1170 1170 1170 1170
Brezza
  • Exteriors
  • Interiors
  • Safety
  • INFOTAINMENT
  • Comfort & Convenience
  • Colour Variants
Exteriors
  LXI MT LXI CNG MT VXI MT VXI AT VXI CNG MT ZXI MT ZXI AT ZXI CNG MT ZXI+ MT ZXI+ AT
Auto Headlamps with Follow me Home & Lead Me to Vehicle
Alloy Wheels
(Painted)
(Painted)
(Painted)
(Precision Cut)
(Precision Cut)
Steel Wheels with Wheel cover
Projector Headlamps
(Bi-Halogen)
(Bi-Halogen)
(Bi-Halogen)
(Bi-Halogen)
(Bi-Halogen)
(Dual LED)
(Dual LED)
(Dual LED)
(Dual LED)
(Dual LED)
Floating LED Day Time Running Lamps
Front Fog Lamps (LED)
Roof Rail
Roof End Spoiler
Chrome Accentuated Front Grille
Rear Combination Lamp (LED)
Shark Fin Antenna
Dual Tone Exterior (In Selected Colours)
Wheel Arch Cladding
Skid Plate (Fr & Rr)
(Black)
(Black)
(Black)
(Black)
(Black)
(Silver)
(Silver)
(Silver)
(Silver)
(Silver)
Side Under Body Cladding
Side Door Cladding
Interiors
  LXI MT LXI CNG MT VXI MT VXI AT VXI CNG MT ZXI MT ZXI AT ZXI CNG MT ZXI+ MT ZXI+ AT
Interior Color Theme
(Mono Tone)
(Mono Tone)
(Mono Tone)
(Mono Tone)
(Mono Tone)
(Dual Tone)
(Dual Tone)
(Dual Tone)
(Dual Tone)
(Dual Tone)
Interior Ambient Lights
Leather Wrapped Steering Wheel^
Co-Driver Side Vanity Lamp
Chrome Plated Inside Door Handles
Door Armrest With Fabric
Luggage Lamp
Glove Box Illumination
Front Footwell Illumination
Cabin Lamp
Flat Bottom Steering Wheel
Rear Parcel Tray
Hook In Luggage Area
IP Ornament
(Black)
(Black)
(Black)
(Black)
(Black)
(Silver)
(Silver)
(Silver)
(Silver)
(Silver)
^Some parts of the leather appointed upholstery will contain man-made material.
Safety
  LXI MT LXI CNG MT VXI MT VXI AT VXI CNG MT ZXI MT ZXI AT ZXI CNG MT ZXI+ MT ZXI+ AT
Head up Display
360 View Camera
Side and Curtain Airbags^^
Shoulder Height Adjustable Front Seat Belts
Electronic Stability Program (ESP)
Hill Hold Assist
Driver & Co-Driver Airbags^^
Rear View Camera
Front Seat Belt Pre-tensioners & Force Limiter
Reverse Parking Sensor with Infographic Display
High Speed Warning Alert#
Seat Belt Reminder Lamp & Buzzer (Driver & Co-Driver)
Rear Wiper & Washer
Rear Defogger (Electric)
Anti-theft Security System
Suzuki TECT Body
Dual Horn
Engine Immobilizer
ISOFIX Child Seat Restraint System
Impact Sensing Door Unlock
Day/Night Rear View Mirror
(Manual)
(Manual)
(Manual)
(Manual)
(Manual)
(Manual)
(Manual)
(Manual)
(Auto)
(Auto)
Door Ajar Warning Lamp
Central Locking
(5 Door)
(5 Door)
(5 Door)
(5 Door)
(5 Door)
(5 Door)
(5 Door)
(5 Door)
(5 Door)
(5 Door)
^^For details on functioning of safety features including air bag, kindly refer to the Owners Manual.
#If the vehicle’s speed exceeds 80 km/h, then the primary level warning will beep twice every minute. And if the vehicle speed goes above 120 km/h, the secondary level warning will keep beeping. If the vehicle speed slows down to 118 km/h, primary warning will resume. If the vehicle is slowed down to 78 km/h, speed alert warning will stop. This buzzer does not include any malfunction in the vehicle.
INFOTAINMENT
  LXI MT LXI CNG MT VXI MT VXI AT VXI CNG MT ZXI MT ZXI AT ZXI CNG MT ZXI+ MT ZXI+ AT
Touch Screen Audio 17.78cm
(SmartPlay Studio)		 17.78cm
(SmartPlay Studio)		 17.78cm
(SmartPlay Studio)		 17.78cm
(SmartPlay Pro)		 17.78cm
(SmartPlay Pro)		 17.78cm
(SmartPlay Pro)		 22.86cm
(SmartPlay Pro+)		 22.86cm
(SmartPlay Pro+)
Premium Sound System ARKAMYS ARKAMYS ARKAMYS ARKAMYS
(Surround Sense)		 ARKAMYS
(Surround Sense)
Android Auto and Apple CarPlay### Wireless Wireless Wireless Wireless Wireless
Remote Control App for Infotainment
Steering Mounted Controls: Audio and Bluetooth
Over the Air Update (OTA)
Onboard Voice Assistant (Wake up through Hi Suzuki with Barge in Feature)
USB & Bluetooth Connectivity
Speakers (4)
Tweeters (2)
MID with TFT Color Display
MID with Segment Display
Speedometer with Tachometer
Audible Headlight On Reminder
Low Fuel Warning Light
Gear Shift Indicator (MT Only)
###Apple and iPhone are trademarks of Apple Inc. registered in the U.S. and other countries. Apple CarPlay is a trademark of Apple Inc., Apple CarPlay is available in the countries listed in the following link: http://www.apple.com/ios/feature-availability/#applecarplay-applecarplay. Apple CarPlay is compatible with the iPhone models listed in the following link: http://www/apple.com/ios/carplay. Android Auto™ extends the Android platform into the car in a way that's purpose-built for driving. It is designed to minimise distraction so you can focus on driving with Google™ services like Google Map™ and Google Search™. Get the Android Auto app on Google Play™. Android Auto is available in the countries listed at the following link: https://www.android.com/auto/#hit-the-road. Most phones with Android 5.0+ work with Android Auto: https://support.google.com/androidauto/#6140477. Android, Android Auto, Google, Google Play and other marks are trademarks of Google Inc.
Comfort & Convenience
  LXI MT LXI CNG MT VXI MT VXI AT VXI CNG MT ZXI MT ZXI AT ZXI CNG MT ZXI+ MT ZXI+ AT
Electric Sunroof
Wireless Charging Dock
Rear Fast Charging USB (Type A and C)
Cruise Control
Height Adjustable Driver Seat
Front Center Armrest (Sliding Type With Storage)
Cooled Glove Box
60:40 Split Seat (Rear)
Overhead Console with Sunglass Holder & Map Lamp
Engine Push Start/stop With Smart Key
Rear Center Armrest With Cup Holder
Adjustable Rear Seat Headrest
Electrically Adjustable ORVM
Electrically Foldable ORVM
(Auto Fold)
(Auto Fold)
Driver Side Front Window (Auto Up/Down)
Rear AC Vents
Auto Climate control
Keyless Entry System
Front & Rear Power Windows
Steering Column Adjustment
(Tilt)
(Tilt)
(Tilt)
(Tilt)
(Tilt)
(Tilt &
Telescopic)
(Tilt &
Telescopic)
(Tilt &
Telescopic)
(Tilt &
Telescopic)
(Tilt &
Telescopic)
Front Accessory Socket
Colour Variants
  LXI MT LXI CNG MT VXI MT VXI AT VXI CNG MT ZXI MT ZXI AT ZXI CNG MT ZXI+ MT ZXI+ AT
Splendid Silver With Midnight Black Roof (Dual Tone)
Sizzling Red with Midnight Black Roof (Dual Tone)
Brave Khakhi with Arctic White Roof (Dual Tone)
Brave Khakhi
Splendid Silver
Sizzling Red
Exuberant Blue
Pearl Arctic White
Magma Grey
  • Engine
  • DIMENSIONS
  • Transmission
  • Brakes
  • Suspension
  • Tyre
Engine
  LXI MT LXI CNG MT VXI MT VXI AT VXI CNG MT ZXI MT ZXI AT ZXI CNG MT ZXI+ MT ZXI+ AT
Engine Type K15C Smart Hybrid K15C K15C Smart Hybrid K15C Smart Hybrid K15C K15C Smart Hybrid K15C Smart Hybrid K15C K15C Smart Hybrid K15C Smart Hybrid
Fuel Type Petrol Mode CNG Mode Petrol Mode Petrol Mode CNG Mode Petrol Mode Petrol Mode CNG Mode Petrol Mode Petrol Mode
Capacity (cc) 1462 1462 1462 1462 1462 1462 1462 1462 1462 1462
Max Power (kW @ RPM) 75.8 @ 6000 74.0 @ 6000
(Gasoline)
64.6 kW @ 5500		 75.8 @ 6000 75.8 @ 6000 74.0 @ 6000
(Gasoline)
64.6 kW @ 5500		 75.8 @ 6000 75.8 @ 6000 74.0 @ 6000
(Gasoline)
64.6 kW @ 5500		 75.8 @ 6000 75.8 @ 6000
Max Torque (Nm @ RPM) 136.8 @ 4400 136.0 @ 4400
(Gasoline)
121.5 Nm @ 4200		 136.8 @ 4400 136.8 @ 4400 136.0 @ 4400
(Gasoline)
121.5 Nm @ 4200		 136.8 @ 4400 136.8 @ 4400 136.0 @ 4400
(Gasoline)
121.5 Nm @ 4200		 136.8 @ 4400 136.8 @ 4400
Emission Type BS VI BS VI BS VI BS VI BS VI BS VI BS VI BS VI BS VI BS VI
Fuel Efficiency 20.15 km/l 25.51 km/kg 20.15 km/l 19.80 km/l 25.51 km/kg 19.89 km/l 19.80 km/l 25.51 km/kg 19.89 km/l 19.80 km/l
Fuel Tank Capacity (L) 48 Petrol: 48
CNG: 55 (Water Equivalent)		 48 48 Petrol: 48
CNG: 55 (Water Equivalent)		 48 48 Petrol: 48
CNG: 55 (Water Equivalent)		 48 48
Idle Start Stop
Brake Energy Regeneration
Torque Assist During Acceleration
Dimensions
  LXI MT LXI CNG MT VXI MT VXI AT VXI CNG MT ZXI MT ZXI AT ZXI CNG MT ZXI+ MT ZXI+ AT
Length(mm) 3995 3995 3995 3995 3995 3995 3995 3995 3995 3995
Width(mm) 1790 1790 1790 1790 1790 1790 1790 1790 1790 1790
Height (unladen) (mm) 1685 1685 1685 1685 1685 1685 1685 1685 1685 1685
Wheelbase (mm) 2500 2500 2500 2500 2500 2500 2500 2500 2500 2500
Seating capacity 5 5 5 5 5 5 5 5 5 5
Boot Space (L) 328* 328* 328* 328* 328* 328* 328*
*VDA Method.
Transmission
  LXI MT LXI CNG MT VXI MT VXI AT VXI CNG MT ZXI MT ZXI AT ZXI CNG MT ZXI+ MT ZXI+ AT
Transmision 5 MT / 6AT 5 MT 5 MT / 6AT 5 MT / 6AT 5 MT 5 MT / 6AT 5 MT / 6AT 5 MT 5 MT / 6AT 5 MT / 6AT
Brakes
  LXI MT LXI CNG MT VXI MT VXI AT VXI CNG MT ZXI MT ZXI AT ZXI CNG MT ZXI+ MT ZXI+ AT
Front Ventilated Disc Ventilated Disc Ventilated Disc Ventilated Disc Ventilated Disc Ventilated Disc Ventilated Disc Ventilated Disc Ventilated Disc Ventilated Disc
Rear Drum Drum Drum Drum Drum Drum Drum Drum Drum Drum
Suspension
  LXI MT LXI CNG MT VXI MT VXI AT VXI CNG MT ZXI MT ZXI AT ZXI CNG MT ZXI+ MT ZXI+ AT
Front Mac Pherson Strut & Coil Mac Pherson Strut & Coil Mac Pherson Strut & Coil Mac Pherson Strut & Coil Mac Pherson Strut & Coil Mac Pherson Strut & Coil Mac Pherson Strut & Coil Mac Pherson Strut & Coil Mac Pherson Strut & Coil Mac Pherson Strut & Coil
Rear Torsion Beam & Coil Spring Torsion Beam & Coil Spring Torsion Beam & Coil Spring Torsion Beam & Coil Spring Torsion Beam & Coil Spring Torsion Beam & Coil Spring Torsion Beam & Coil Spring Torsion Beam & Coil Spring Torsion Beam & Coil Spring Torsion Beam & Coil Spring
Tyre
  LXI MT LXI CNG MT VXI MT VXI AT VXI CNG MT ZXI MT ZXI AT ZXI CNG MT ZXI+ MT ZXI+ AT
Tyre Size 215/60 R16## 215/60 R16## 215/60 R16## 215/60 R16## 215/60 R16## 215/60 R16## 215/60 R16## 215/60 R16## 215/60 R16## 215/60 R16##
##Spare wheel material is steel & spare tyre size is 215/60 R16.
WagonR
  • Interiors
  • Instrument Cluster
  • Comfort and Convenience
  • Infotainment System
  • Safety and Security
  • Exteriors
Interiors
  LXI 1.0L LXI CNG 1.0L VXI 1.0L VXI AGS 1.0L VXI CNG 1.0L ZXI 1.2L ZXI AGS 1.2L ZXI+ 1.2L ZXI+ AGS 1.2L
Dual Tone Interiors
2nd Row 60:40 Split Seat
Front Cabin Lamps (3 Positions)
Day/Night IRVM
Tilt Steering
Steering Wheel Garnish
Silver Inside Door Handles
Driver Side Sunvisor with Ticket Holder
Front Passenger Side Vanity Mirror Sunvisor
Silver Finish Gear Shift Knob (AGS only)
Instrument Cluster
  LXI 1.0L LXI CNG 1.0L VXI 1.0L VXI AGS 1.0L VXI CNG 1.0L ZXI 1.2L ZXI AGS 1.2L ZXI+ 1.2L ZXI+ AGS 1.2L
Instrument Cluster Meter Theme Reddish Amber Reddish Amber Reddish Amber Reddish Amber Reddish Amber Reddish Amber Reddish Amber White White
Low Fuel Warning
Tachometer
Gear Shift Indicator (MT Only)
Gear Position Indicator (AGS Only)
Fuel Consumption  (Instantaneous and Average)
Distance to empty
Headlamp On Warning
Door Ajar Warning Lamp
Comfort and Convenience
  LXI 1.0L LXI CNG 1.0L VXI 1.0L VXI AGS 1.0L VXI CNG 1.0L ZXI 1.2L ZXI AGS 1.2L ZXI+ 1.2L ZXI+ AGS 1.2L
Idle Start Stop(ISS) (Petrol) (Petrol) (Petrol) (Petrol) (Petrol)
Remote Keyless Entry
Accessory Socket Front Row with Storage Space
Power Windows (Fr/Rr) with Dr. Slide Auto Down Function Only Front Only Front
AC & Heater
1L Bottle Holders (All Four Doors + Floor Console)
Rear Parcel Tray CNG Only CNG Only
Co. Driver Side Front Seat Under Tray and Rear Back Pocket
Reclining & Front Sliding Seats
Infotainment System
  LXI 1.0L LXI CNG 1.0L VXI 1.0L VXI AGS 1.0L VXI CNG 1.0L ZXI 1.2L ZXI AGS 1.2L ZXI+ 1.2L ZXI+ AGS 1.2L
17.78 cm Smartplay Studio with Smartphone Navigation
Smartplay Dock
Apple Carplay and Android Auto
Bluetooth
Number of Speakers 2 2 2 2 2 4 4
USB Connectivity/AUX
Steering Mounted Audio Control
Steering Mounted Voice Control
Safety And Security
  LXI 1.0L LXI CNG 1.0L VXI 1.0L VXI AGS 1.0L VXI CNG 1.0L ZXI 1.2L ZXI AGS 1.2L ZXI+ 1.2L ZXI+ AGS 1.2L
Driver Airbag##
Passenger Airbag
ABS with EBD
Electronic Stability Program (ESP)
Seat Belt Pre-tensioner and Force Limiters (Dr.+Co-Dr.)
Seat Belt Reminder with Buzzer (Front & Rear Seat)^^#
Seat Belts for all seats^^^
Speed Alert System^^
Speed Sensitive Auto Door Lock
Security Alarm
Rear Parking Sensors
Central Locking
Child Proof Rear Door Lock
Front Fog Lamps
Hill Hold Assist AGS AGS AGS AGS AGS AGS AGS
##For details on functioning of safety features, including air bag, kindly refer to the Owner's Manual.
^^#Seat belt reminder comes on unless all rear passenger's seat belts are fastened irrespective of the presence or absence of passenger.
^^^Rear Centre seat has lap belt type of seat belt.
^^The speed alert system gives audible warning for alert of over-speed to driver. When the vehicle speed exceeds about 80km/h, primary level warning with two beeps will sound every minute. When the vehicle speed exceeds about 120km/h, secondary level warning with continuous beeps will sound. If the vehicle speed is slowed down to about 118km/h, primary warning will resume. If the vehicle is slowed down to 78km/h, speed alert warning will stop. This buzzer does not indicate any malfunction in vehicle.
Exteriors
  LXI 1.0L LXI CNG 1.0L VXI 1.0L VXI AGS 1.0L VXI CNG 1.0L ZXI 1.2L ZXI AGS 1.2L ZXI+ 1.2L ZXI+ AGS 1.2L
Roof Antenna
Full Wheel Cover (Center Cap) (Center Cap)
Alloy Wheels
ORVM with Turn Indicators
Electrical Adjustable ORVM
Electrical Retractable ORVM
Rear Wiper and Washer
B-Pillar Black Out Tape
Body Coloured Door Handles
Body Coloured Bumpers
Body Coloured ORVMs (Black In Dual tone) (Black in Dual Tone)
Dual Tone Exteriors (Optional) (Optional)
  • Dimensions
  • Engine & Transmission
  • Suspension
  • Capacities
  • Wheels and Tyres
  • Brakes
  • Weight
DIMENSIONS
  LXI 1.0L LXI CNG 1.0L VXI 1.0L VXI AGS 1.0L VXI CNG 1.0L ZXI 1.2L ZXI AGS 1.2L ZXI+ 1.2L ZXI+ AGS 1.2L
Length (mm) 3655 3655 3655 3655 3655 3655 3655 3655 3655
Width (mm) 1620 1620 1620 1620 1620 1620 1620 1620 1620
Height (mm) 1675 1675 1675 1675 1675 1675 1675 1675 1675
Wheelbase (mm) 2435 2435 2435 2435 2435 2435 2435 2435 2435
Turning Radius (m) 4.7 4.7 4.7 4.7 4.7 4.7 4.7 4.7 4.7
Engine & Transmission
  LXI 1.0L LXI CNG 1.0L VXI 1.0L VXI AGS 1.0L VXI CNG 1.0L ZXI 1.2L ZXI AGS 1.2L ZXI+ 1.2L ZXI+ AGS 1.2L
Type K10C K10C K10C K10C K10C K12N K12N K12N K12N
Capacity (cc) 998 998 998 998 998 1197 1197 1197 1197
Number of Cylinders 3 3 3 3 3 4 4 4 4
Maximum engine
output(kW @ rpm)		 49.0 kW (66.62 PS) @ 5500 rpm 41.7 kW (56.70 PS) @ 5300 rpm (CNG mode)
48.0 kW (65.26 PS) @ 5500 rpm (Petrol mode) 		49.0 kW (66.62 PS) @ 5500 rpm 49.0 kW (66.62 PS) @ 5500 rpm 41.7 kW (56.70 PS) @ 5300 rpm (CNG mode)
48.0 kW (65.26 PS) @ 5500 rpm (Petrol mode) 		66 kW (89.73 PS) @ 6000 rpm 66 kW (89.73 PS) @ 6000 rpm 66 kW (89.73 PS) @ 6000 rpm 66 kW (89.73 PS) @ 6000 rpm
Maximum torque (Nm @ rpm) 89.0 Nm @ 3500 rpm 82.1 Nm @ 3400 rpm (CNG mode)
89.0 Nm @ 3500 rpm (Petrol mode) 		89.0 Nm @ 3500 rpm 89.0 Nm @ 3500 rpm 82.1 Nm @ 3400 rpm (CNG mode)
89.0 Nm @ 3500 rpm (Petrol mode) 		113 Nm @ 4400 rpm 113 Nm @ 4400 rpm 113 Nm @ 4400 rpm 113 Nm @ 4400 rpm
Transmission MT MT MT AGS MT MT/AGS AGS MT/AGS AGS
Suspension
  LXI 1.0L LXI CNG 1.0L VXI 1.0L VXI AGS 1.0L VXI CNG 1.0L ZXI 1.2L ZXI AGS 1.2L ZXI+ 1.2L ZXI+ AGS 1.2L
Front MacPherson Strut with Coil Spring MacPherson Strut with Coil Spring MacPherson Strut with Coil Spring MacPherson Strut with Coil Spring MacPherson Strut with Coil Spring MacPherson Strut with Coil Spring MacPherson Strut with Coil Spring MacPherson Strut with Coil Spring MacPherson Strut with Coil Spring
Rear Torsion Beam with Coil Spring Torsion Beam with Coil Spring Torsion Beam with Coil Spring Torsion Beam with Coil Spring Torsion Beam with Coil Spring Torsion Beam with Coil Spring Torsion Beam with Coil Spring Torsion Beam with Coil Spring Torsion Beam with Coil Spring
Capacities
  LXI 1.0L LXI CNG 1.0L VXI 1.0L VXI AGS 1.0L VXI CNG 1.0L ZXI 1.2L ZXI AGS 1.2L ZXI+ 1.2L ZXI+ AGS 1.2L
Seating Capacity 5 5 5 5 5 5 5 5 5
Fuel Tank Capacity (L) 32 (Petrol)/ 60
(Water equivalent) 		32 (Petrol)/ 60
(Water equivalent) 		32 (Petrol)/ 60
(Water equivalent) 		32 (Petrol)/ 60
(Water equivalent) 		32 (Petrol)/ 60
(Water equivalent) 		32 (Petrol) 32 (Petrol) 32 (Petrol) 32 (Petrol)
Boot Space (Litres) 341^ (Petrol) 341^ (Petrol) 341^ (Petrol) 341^ (Petrol) 341^ (Petrol) 341^ (Petrol) 341^ (Petrol) 341^ (Petrol) 341^ (Petrol)
^VDA Method.
Wheels and Tyres
  LXI 1.0L LXI CNG 1.0L VXI 1.0L VXI AGS 1.0L VXI CNG 1.0L ZXI 1.2L ZXI AGS 1.2L ZXI+ 1.2L ZXI+ AGS 1.2L
Size 155/80R13 155/80R13 165/70R14 165/70R14 165/70R14 165/70R14 165/70R14 165/70R14 165/70R14
Type** Radial & Tubeless, Steel Wheels Radial & Tubeless, Steel Wheels Radial & Tubeless, Steel Wheels Radial & Tubeless, Steel Wheels Radial & Tubeless, Steel Wheels Radial & Tubeless, Steel Wheels Radial & Tubeless, Steel Wheels Radial & Tubeless, Alloy Wheels Radial & Tubeless, Alloy Wheels
**Spare Wheel Material is steel(for all variants).
Brakes
  LXI 1.0L LXI CNG 1.0L VXI 1.0L VXI AGS 1.0L VXI CNG 1.0L ZXI 1.2L ZXI AGS 1.2L ZXI+ 1.2L ZXI+ AGS 1.2L
Front Disc Disc Disc Disc Disc Disc Disc Disc Disc
Rear Drum Drum Drum Drum Drum Drum Drum Drum Drum
Weight
  LXI 1.0L LXI CNG 1.0L VXI 1.0L VXI AGS 1.0L VXI CNG 1.0L ZXI 1.2L ZXI AGS 1.2L ZXI+ 1.2L ZXI+ AGS 1.2L
Gross Vehicle Weight (kg) 1340 1340 1340 1340 1340 1340 1340 1340 1340
Kerb Weight (kg) 810 910 825 835 920 835 840 845 850

Alto

Ex-showroom Price

2 99 748 - 4 41 248

Mileage

Petrol - 22.05 km/l* CNG - 31.59 km/kg#

*For Petrol Variants only. #In CNG mode CNG variants only. As certified by Test Agency Under Rule 115 (G) of CMVR 1989

download brochure
  • SAFETY
  • COMFORT & CONVENIENCE
  • INSTRUMENTS CLUSTER
  • INTERIOR & SEAT
  • EXTERIOR
SAFETY
LX LXI LXI CNG VXI VXI (O) VXI AGS
Driver Airbag


Reverse parking Sensor


Seat Belt Reminder - Dr+ Co Dr


Speed Alert System




Front Fog Lamps - - - -
Front Seat Belt: 3-point ELR Seat Belts


Rear Seat Belt
3-point ELR SeatBelts x 2


2-point Fix Seat Belt x 1
-
High Mounted Stop Lamp


Front Disc Brake Ventilated Ventilated Ventilated Ventilated Ventilated Ventilated
Child - Proof Rear Door Locks


COMFORT & CONVENIENCE
LX LXI LXI CNG VXI VXI (O) VXI AGS
Air Conditioner


Power Steering


Audio (CD-MP3-USB,RADIO)


Antenna

Number of Speakers 2 2 2
Keyless Entry
_
Central Door Locking

Tailgate Opener


Front Power Window

Key off Audible Reminder

Head Lamp on Warning Buzzer

Internally Adjustable ORVM _

Rear Parcel Tray


Instruments Cluster
LX LXI LXI CNG VXI VXI (O) VXI AGS
Tachometer

Shift Up Indicator

Gear Shift Digital Display (Auto Gear Shift)
Accessory Socket


Digital Clock

Dial-type Climate Control

INTERIOR & SEAT
LX LXI LXI CNG VXI VXI (O) VXI AGS
Sun Visor (Dr+Co-Dr)



Vanity Mirrors ( Co-Dr)
 ( Co-Dr)
 ( Co-Dr)
Cabin Light (3-Position) ( Front)
 ( Front) ( Front) ( Front) ( Front) ( Front)
Floor Console with 2 Cup Holders



Piano Black Finish I/P Center Garnish


Silver Accent (Side Louvers, Steering Wheel,Inside Door Handle, Console Garnish Ring, Panel Instrument cluster garnish,Door trim armrest)

EXTERIOR
LX LXI LXI CNG VXI VXI (O) VXI AGS
Chrome Front Grille

Body Coloured Bumper

Body Coloured Door Mirror

Body Coloured Outside Door Handles

B Pillar Black-Out Tape

Full Wheel Covers


Body Side Molding

  • Brakes
  • Capacity
  • Dimension
  • Engine
  • Suspension System
  • Weight
Brakes
LX LXI LXI CNG VXI VXI (O) VXI AGS
Front Ventilated Disk Ventilated Disk Ventilated Disk Ventilated Disk Ventilated Disk Ventilated Disk
Rear Drum Drum Drum Drum Drum Drum
Capacity
LX LXI LXI CNG VXI VXI (O) VXI AGS
Seating 5 Persons 5 Persons 4 Persons 5 Persons 5 Persons 5 Persons
Fuel Tank Capacity  35 L (Gasoline) 35 L (Gasoline) 60 L (Water Equivalent Capacity - CNG)
 35 L (Gasoline) 35 L (Gasoline)
 35 L (Gasoline)
Dimensions
LX LXI LXI CNG VXI VXI (O) VXI AGS
Overall Length 3545 mm 3545 mm 3545 mm 3545 mm 3545 mm 3545 mm
Overall Width (without Body Side Moulding) 1490 mm  1490 mm 1490 mm 1490 mm 1490 mm 1490 mm
Overall Width (with Body Side Moulding) 1515 mm  1515 mm 1515 mm 1515 mm 1515 mm 1515 mm
Overall Height 1475 mm 1475 mm 1475 mm 1475 mm 1475 mm 1475 mm
Tread (Front) 1295 mm 1295 mm 1295 mm 1295 mm 1295 mm  1295 mm
Tread (Rear) 1290 mm  1290 mm 1290 mm 1290 mm 1290 mm 1290 mm
Turning Radius 4.6 m 4.6 m 4.6 m 4.6 m 4.6 m 4.6 m
Wheelbase 2360 mm 2360 mm 2360 mm 2360 mm 2360 mm 2360 mm
Engine
LX LXI LXI CNG VXI VXI (O) VXI AGS
Fuel GASOLINE GASOLINE CNG + GASOLINE GASOLINE GASOLINE
 GASOLINE
Transmission 5MT 5MT 5MT 5MT 5MT AMT
Emission Type BS IV + OBD II BS IV + OBD II BS IV + OBD II BS IV + OBD II BS IV + OBD II BS IV + OBD II
Maximum Torque 90 Nm 3500 rpm (Gasoline) 90 Nm 3500 rpm (Gasoline) 78 Nm 3500 rpm (CNG) 90 Nm 3500 rpm (Gasoline) 90 Nm 3500 rpm (Gasoline)
 90 Nm 3500 rpm (Gasoline)
Engine (Cubic Capacity) K10B (998cc) K10B (998cc) K10B (998cc) K10B (998cc) K10B (998cc) K10B (998cc)
Maximum Power 50 kW  6000 rpm (Gasoline) 50 kW  6000 rpm (Gasoline) 43.5 kW 6000 rpm (CNG)
 50 kW  6000 rpm (Gasoline)
 50 kW  6000 rpm (Gasoline)
 50 kW  6000 rpm (Gasoline)
Suspension System
LX LXI LXI CNG VXI VXI (O) VXI AGS
Front Gas Filled MacPherson Strut
 Gas Filled MacPherson Strut Gas Filled MacPherson Strut Gas Filled MacPherson Strut Gas Filled MacPherson Strut Gas Filled MacPherson Strut
Rear 3 Link Rigid Axle Suspension
 3 Link Rigid Axle Suspension 3 Link Rigid Axle Suspension 3 Link Rigid Axle Suspension 3 Link Rigid Axle Suspension
 3 Link Rigid Axle Suspension
Tyre Size
 155/65 R13
 155/65 R13  155/65 R13  155/65 R13  155/65 R13  155/65 R13
Weight
LX LXI LXI CNG VXI VXI (O) VXI AGS
Gross Weight 1210 Kg 1210 Kg 1210 Kg 1210 Kg 1210 Kg 1210 Kg
Kerb Weight 769 Kg 774 Kg 867 Kg 779 Kg 784 Kg 784 Kg

Get A Quote

Disclaimer: I agree that by clicking the 'Submit' button below, I am explicitly soliciting a call from Maruti Suzuki India Ltd. or its partners on my 'Mobile' in order to assist me with the selection of a car. I confirm that details entered here are mine and shall be used by Maruti Suzuki India Ltd. or its partners to contact me.

Get A Quote+

about us

ABT Maruti is an authorized and renowned dealer for Maruti Suzuki ARENA. Buy Maruti Suzuki ARENA cars - Swift, S-Presso, Vitara Brezza, Ertiga, Dzire, Celerio, Alto, Celerio X, Eeco and WagonR with us. ABT Maruti have a stronghold in Mettupalayam with a strong market presence and experience in the automobile industry. We have been associated with Maruti Suzuki through our authorized showrooms. We are a group of highly trained technicians and friendly staff who believe in making our customer's buying experience easier and comfortable by providing excellent and prompt customer support and strive hard to improve it with every visit. Our goal is to add joy in your journey.

Know us

ABT - Maruti Suzuki ARENA Showroom in Ponvizha Nagar, Mettupalayam

 ABT is one of the top car dealerships of Ponvizha Nagar, Mettupalayam. We are a team of hard-working expert professionals who strive to make your car buying journey a memorable one.
ABT houses a wide range of Maruti Suzuki cars for you to choose from including Alto, Alto K10, WagonR, Celerio, Swift, Dzire, Ertiga, Brezza, S-Presso, Eeco. The cars are equipped with dual-front airbags, seatbelt pre-tensioners, reverse parking camera, child seat anchorages, high-speed warning and rear defogger. As an active part of the green-fuel initiative, we also house the S-CNG segment, where you can enjoy better performance, more efficiency, more mileage, and more durability. ABT also houses the BSVI compliant segment of Maruti Suzuki ARENA cars.
At ABT our constantly evolving efforts are in sync with the needs of our customers. Our website offers many services, such as, an EMI calculator, model specific brochures containing all the features of every car, ex-showroom prices, and even the option to get a quote.
For more information, visit ABT at Ponvizha Nagar, Mettupalayam.

Our Team

CONTACT US

Mettupalayam

Maruti Suzuki ARENA, Mettupalayam
ABT Pvt. Ltd.
Site No. 7,8 & 9, Ponvizha Nagar, Coimbatore main road, Mettupalayam, Tamil Nadu - 641301
mpsales@abtmaruti.com
OPENING HOURS

Mon - Sun : 09:00 AM - 06:00 PM

customer testimonials

Copyright © Maruti Suzuki India Limited

Privacy Policy
